Microchip Technology ATTINY24A-CCU
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $6.68 | $6.68 |
| 15+ | $1.54 | $23.10 |
| 25+ | $1.50 | $37.50 |
| 50+ | $1.42 | $71.00 |
| 100+ | $1.25 | $125.00 |
| N+ | $0.25 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | AVR® ATtiny |
| Packaging | Tray | Tray |
| Core Processor | AVR |
| Core Size | 8-Bit |
| Speed | 20MHz |
| Connectivity | USI |
| Peripherals | Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT |
| Number of I/O | 12 |
| Program Memory Size | 2KB (1K x 16) |
| Program Memory Type | FLASH |
| EEPROM Size | 128 x 8 |
| RAM Size | 128 x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Data Converters | A/D 8x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 15-UFBGA (3x3) |
| Package / Case | 15-UFBGA |
| ROHS |  |
The ATTINY24A-CCU from Atmel is a tiny 8-bit AVR microcontroller in a 15-ball UFBGA package. It runs at 20MHz with 2KB flash and 128 bytes RAM, operating from 1.8V to 5.5V. Integrated features include brown-out detection, POR, PWM, temperature sensor, and WDT, making it a versatile choice for ultra-compact embedded applications.
- Ultra-miniature footprint: 15-ball UFBGA enables designs smaller than 3x3mm.
- Wide voltage range: 1.8V to 5.5V simplifies interfacing with both 3.3V and 5V peripherals.
- On-chip temperature sensor: Eliminates external components for thermal monitoring.
- Low-power AVR core: Optimized for battery-powered devices with sleep modes.
Miniature Wearable Sensors
The 15-ball UFBGA package is among the smallest available, enabling ultra-compact fitness and health monitoring devices.
Battery Management in IoT
With 1.8V operation and integrated temperature sensor, it monitors battery voltage and temperature in smart tags.
LED Lighting Effects
PWM channels drive RGB LEDs in decorative lighting, with the temp sensor preventing thermal runaway.
Consumer Toys and Games
Low cost and 5.5V tolerance make it ideal for interactive toys with sound and motion control.
Automotive Interior Lighting
Operating from -40°C to 85°C, it controls ambient lighting strips in vehicle cabins.
Security Key Fobs
Its small size and low power suit remote keyless entry transmitters with rolling code algorithms.
