Cypress Semiconductor Corp CY27020SC
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $5.60 | $5.60 |
| 15+ | $1.29 | $19.35 |
| 25+ | $1.26 | $31.50 |
| 50+ | $1.19 | $59.50 |
| 100+ | $1.05 | $105.00 |
| N+ | $0.21 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Cypress Semiconductor Corp |
| Product Series | |
| Packaging | Bulk | |
| Type | Spread Spectrum Clock Generator |
| PLL | Yes |
| Input | Crystal |
| Output | Clock |
| Number of Circuits | 1 |
| Ratio - Input:Output | 1:2 |
| Differential - Input:Output | No/No |
| Frequency - Max | 48MHz |
| Divider/Multiplier | No/No |
| Voltage - Supply | 2.97V ~ 3.63V |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
The CY27020SC is a Spread Spectrum Clock Generator from Cypress Semiconductor, featuring an integrated PLL for frequency synthesis and EMI reduction. With a single circuit supporting up to 48MHz, this device accepts a crystal input and delivers modulated clock outputs. It operates over 0°C to 70°C and is housed in a compact 8-SOIC package, making it ideal for consumer electronics and industrial applications requiring EMI compliance.
- Spread spectrum modulation: Reduces EMI by up to 10dB, simplifying compliance with FCC and CE regulations.
- Integrated PLL: Provides frequency synthesis and modulation in a single device, reducing component count.
- Crystal input interface: Allows direct connection to a low-cost crystal, eliminating the need for an external oscillator.
- Compact 8-SOIC package: Saves PCB space in space-constrained designs.
- Wide operating temperature range: Reliable performance from 0°C to 70°C for commercial applications.
EMI Reduction in Consumer Electronics
Use the CY27020SC in set-top boxes, DVD players, and gaming consoles to reduce electromagnetic interference and pass FCC/CE compliance testing.
PC and Laptop Clocking
In desktop PCs and laptops, this spread spectrum clock generator minimizes EMI from high-speed interfaces like USB, SATA, and PCIe.
Networking Equipment
For routers, switches, and modems, the CY27020SC reduces radiated emissions from Ethernet and wireless interfaces.
Industrial Control Systems
In PLCs and industrial computers, this device helps meet EMC standards while providing stable clock signals for microcontrollers.
Automotive Infotainment
Use this spread spectrum clock generator in car audio and navigation systems to reduce EMI and improve signal integrity.
Medical Devices
For sensitive medical monitoring equipment, the CY27020SC reduces interference with other electronic devices in clinical environments.
- Q: What type of device is the CY27020SC?
- A: The CY27020SC is a Spread Spectrum Clock Generator from Cypress Semiconductor, designed to reduce electromagnetic interference (EMI).
- Q: Does the CY27020SC include a PLL?
- A: Yes, this device features an integrated Phase-Locked Loop (PLL) for frequency synthesis and spread spectrum modulation.
- Q: What are the input and output types?
- A: The input type is Crystal, and the output type is Clock. It accepts a crystal oscillator input and provides clock output signals.
- Q: How many circuits does it have and what is the maximum frequency?
- A: It has 1 circuit and supports a maximum frequency of 48MHz.
- Q: What is the operating temperature range?
- A: The operating temperature range is 0°C to 70°C (TA).
- Q: What package is the CY27020SC available in?
- A: It comes in an 8-SOIC (0.154", 3.90mm Width) package.
