Cypress Semiconductor Corp CY74FCT162827BTPVC
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $2.04 | $2.04 |
| 15+ | $0.47 | $7.05 |
| 25+ | $0.46 | $11.50 |
| 50+ | $0.43 | $21.50 |
| 100+ | $0.38 | $38.00 |
| N+ | $0.08 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Cypress Semiconductor Corp |
| Product Series | 74FCT |
| Packaging | Bulk | |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 2 |
| Number of Bits per Element | 10 |
| Input Type | - |
| Output Type | 3-State |
| Current - Output High, Low | 24mA, 24mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 56-BSSOP (0.295", 7.50mm Width) |
| Supplier Device Package | 56-SSOP |
| ROHS |  |
The CY74FCT162827BTPVC from Cypress Semiconductor is a dual non-inverting buffer designed for 5V systems. It features two channels with 3-State outputs, each delivering 24mA drive current. The 56-BSSOP package is suitable for dense PCB layouts. This buffer is ideal for bus interfacing, memory address buffering, and signal distribution in industrial and telecom applications where 5V logic is still prevalent.
- 5V Operation (4.5V–5.5V): Directly compatible with legacy TTL and 5V CMOS logic.
- 24mA Output Drive: Ensures reliable signal transmission over long traces.
- 3-State Outputs: Facilitates bus multiplexing and bidirectional data flow.
- Wide Temperature Range (-40°C to 85°C): Suitable for industrial environments.
5V Legacy Bus Buffering
Operating at 4.5V–5.5V, this buffer interfaces with older 5V microprocessors and peripherals, ensuring compatibility with existing infrastructure.
High-Density Backplane Drivers
The 24mA output current drives multiple loads on a backplane, maintaining signal levels across long distances in telecom and networking equipment.
Memory Address Buffering
Non-inverting 3-State outputs isolate address lines, reducing loading on memory controllers and improving timing margins in high-speed SRAM/DRAM systems.
Industrial PLC I/O Modules
With -40°C to 85°C rating, it buffers control signals in programmable logic controllers, providing robust performance in factory automation.
Test Equipment Signal Distribution
3-State outputs allow multiple instruments to share a common data bus without interference, simplifying automated test setups.
Server Motherboard Chipset Interfacing
Buffers chipset-to-peripheral signals, ensuring clean logic levels for PCI and ISA buses in server platforms.
- Q: What logic family does the CY74FCT162827BTPVC use?
- A: It is based on the 74FCT family, optimized for 5V high-speed operation.
- Q: What is the function of this device?
- A: It is a dual-channel non-inverting buffer with 3-State outputs.
- Q: How many channels are available?
- A: It provides 2 independent buffer channels.
- Q: What is the output type?
- A: 3-State outputs allow high-impedance states for bus sharing.
- Q: What is the supply voltage range?
- A: It operates from 4.5V to 5.5V, ideal for legacy 5V systems.
- Q: What package is used?
- A: It comes in a 56-BSSOP (0.295", 7.50mm width) package.
