Cypress Semiconductor Corp CY8C20324-12LQXI
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $8.76 | $8.76 |
| 15+ | $1.88 | $28.20 |
| 25+ | $1.84 | $46.00 |
| 50+ | $1.73 | $86.50 |
| 100+ | $1.53 | $153.00 |
| N+ | $0.31 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Cypress Semiconductor Corp |
| Product Series | PSOC®1 CY8C20xxx |
| Packaging | Bulk | |
| Core Processor | M8C |
| Core Size | 8-Bit |
| Speed | 12MHz |
| Connectivity | I2C, SPI |
| Peripherals | LVD, POR, WDT |
| Number of I/O | 20 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.4V ~ 5.25V |
| Data Converters | - |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 24-QFN (4x4) |
| Package / Case | 24-UFQFN Exposed Pad |
| ROHS |  |
The Cypress CY8C20324-12LQXI is a versatile 8-bit MCU based on the M8C core, running at 12MHz. It provides 8KB flash and 512 bytes of RAM, operating from 2.4V to 5.25V. With LVD, POR, and WDT, it ensures stable operation in consumer and industrial applications. The 24-UFQFN package is ideal for compact, touch-enabled designs.
- Wide voltage range (2.4V-5.25V): Compatible with both 3.3V and 5V peripherals.
- 8KB flash: Sufficient for touch sensing and user interface firmware.
- M8C core at 12MHz: Balanced performance for interactive applications.
- 24-UFQFN package: Ultra-thin profile for wearable and portable devices.
Capacitive Touch Buttons
The Cypress PSoC architecture with M8C core supports touch sensing with 8KB flash for calibration algorithms.
Portable Gaming Controllers
2.4V-5.25V range allows direct battery connection, while 512B RAM handles button debounce and LED effects.
Industrial Keypads
With WDT and LVD, it ensures reliable operation in noisy environments with 12MHz processing.
Smart Toys
Low cost and small package enable interactive features with PWM for sound and motion.
Medical Gloves
Flexible UFQFN package fits on thin PCBs for gesture detection in rehabilitation devices.
Home Automation Panels
8KB flash supports multiple sensor inputs and relay control with 5V logic compatibility.
- Q: What core does the CY8C20324-12LQXI use?
- A: It uses the M8C core, running at 12MHz.
- Q: What is the supply voltage range?
- A: It operates from 2.4V to 5.25V, covering both 3V and 5V systems.
- Q: How much flash and RAM are available?
- A: It has 8KB flash and 512 bytes of RAM.
- Q: What package is it offered in?
- A: It comes in a 24-UFQFN exposed pad package.
- Q: Does it have watchdog and reset features?
- A: Yes, it includes LVD, POR, and WDT.
