Cypress Semiconductor Corp CY8C4024FNI-S412T
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $5.96 | $5.96 |
| 15+ | $1.24 | $18.60 |
| 25+ | $1.22 | $30.50 |
| 50+ | $1.15 | $57.50 |
| 100+ | $1.01 | $101.00 |
| N+ | $0.20 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Cypress Semiconductor Corp |
| Product Series | PSOC® 4 CY8C4000S |
| Packaging | Tape & Reel (TR) | |
| Core Processor | ARM® Cortex®-M0+ |
| Core Size | 32-Bit Single-Core |
| Speed | 24MHz |
| Connectivity | I2C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART |
| Peripherals | Brown-out Detect/Reset, CapSense, LCD, LVD, POR, PWM, WDT |
| Number of I/O | 21 |
| Program Memory Size | 16KB (16K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 5.5V |
| Data Converters | A/D 1x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 25-WLCSP (2.02x1.93) |
| Package / Case | 25-XFBGA, WLCSP |
| ROHS |  |
The Cypress CY8C4024FNI-S412T is a 32-bit ARM Cortex-M0+ MCU with 16KB flash and 2KB RAM, running at 24MHz. Its standout feature is integrated CapSense, enabling touch interfaces without external components. The 25-XFBGA WLCSP package is ultra-compact, ideal for wearables and IoT devices. It operates from 1.71V to 5.5V and includes LCD drive, LVD, POR, PWM, and WDT. The -40°C to 85°C range covers most consumer and industrial applications.
- Integrated CapSense – eliminates external touch controllers, saving BOM cost.
- Ultra-small WLCSP package – enables miniaturized product designs.
- Wide voltage range (1.71V-5.5V) – flexible power source options.
- LCD drive capability – supports direct segment LCD connection.
Touch-Sensitive Control Panels
Integrated CapSense eliminates external touch ICs, reducing cost and board space in appliances.
Wearable Devices
The tiny WLCSP package and 1.71V operation enable compact, battery-powered health monitors.
Smart Home Sensors
Low-power modes and LCD drive make it suitable for thermostats and occupancy sensors.
Portable Instrumentation
With 16KB flash and 2KB RAM, it can handle basic data logging and display control.
Industrial HMI
CapSense buttons and PWM backlight control provide a modern user interface for machinery.
IoT End Nodes
Wide voltage range and low sleep current support long-life battery operation.
- Q: What is the supply voltage range?
- A: It operates from 1.71V to 5.5V, supporting both low-power and standard applications.
- Q: Does it support capacitive sensing?
- A: Yes, it includes CapSense technology for touch interfaces.
- Q: What is the package type?
- A: It comes in a 25-XFBGA WLCSP package, ideal for space-constrained designs.
- Q: What is the maximum clock speed?
- A: The ARM Cortex-M0+ core runs at up to 24MHz.
- Q: What are the key integrated peripherals?
- A: It features LCD drive, LVD, POR, PWM, WDT, and brown-out detection.
