Microchip Technology DSC2011FI2-E0005T
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | DSC2011 |
| Packaging | | |
| Type | Clock Generator |
| PLL | Yes |
| Input | - |
| Output | LVCMOS |
| Number of Circuits | 1 |
| Ratio - Input:Output | 0:2 |
| Differential - Input:Output | No/No |
| Frequency - Max | 25MHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 2.25V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 14-VFQFN Exposed Pad |
| Supplier Device Package | 14-QFN (3.2x2.5) |
| ROHS |  |
The Microchip DSC2011FI2-E0005T is a Clock Generator featuring an integrated PLL, providing a stable 25MHz LVCMOS output. This single-circuit device is ideal for Ethernet, FPGA, and industrial control applications. Housed in a 14-VFQFN Exposed Pad package and rated for -40°C to 85°C, it delivers reliable performance across a wide range of operating conditions.
- Standard 25MHz Output: Directly compatible with common Ethernet PHYs and microcontrollers, simplifying system design.
- Integrated PLL: Ensures low-jitter clock generation, critical for high-speed digital communication.
- Compact 14-VFQFN Package: Ideal for space-constrained PCB layouts, enabling miniaturized product designs.
- Industrial Temperature Rating: -40°C to 85°C operation makes it suitable for factory automation and outdoor equipment.
Ethernet Switch Timing
The 25MHz output is a standard reference for 100BASE-T and 1000BASE-T Ethernet PHYs, ensuring reliable network communication.
FPGA Configuration Clock
Provide a stable clock for FPGA configuration logic and internal state machines, enabling deterministic system startup.
Industrial Motor Control
Use this clock generator to synchronize PWM controllers and motor drivers, improving efficiency and reducing electromagnetic interference.
Point-of-Sale Terminals
Generate the main system clock for POS devices, ensuring reliable operation of payment processing and display interfaces.
Building Automation Controllers
Clock microcontrollers in HVAC and lighting control systems, providing accurate timing for sensor polling and actuator control.
Portable Instrumentation
Provide a low-power, stable clock for handheld multimeters and signal generators, extending battery life while maintaining accuracy.
