Microchip Technology DSC2130FE1-C0003
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | DSC2130 |
| Packaging | | |
| Type | Clock Generator |
| PLL | Yes |
| Input | - |
| Output | LVDS |
| Number of Circuits | 1 |
| Ratio - Input:Output | 0:1 |
| Differential - Input:Output | No/Yes |
| Frequency - Max | 150MHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 2.25V ~ 3.6V |
| Operating Temperature | -20°C ~ 70°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 14-VFQFN Exposed Pad |
| Supplier Device Package | 14-QFN (3.2x2.5) |
| ROHS |  |
The Microchip DSC2130FE1-C0003 is a single-output clock generator with integrated PLL, delivering a fixed 150MHz LVDS clock. This device is optimized for high-speed digital systems requiring low jitter and reliable performance. Its compact 14-VFQFN package and commercial temperature range make it suitable for networking, FPGA, and industrial applications.
- Low-Jitter LVDS Output: Provides clean 150MHz clocking for high-speed data converters and transceivers, improving system bit-error-rate.
- Integrated PLL: Reduces external component count and simplifies clock tree design, lowering overall system cost.
- Compact Package: The 14-VFQFN Exposed Pad package enables dense PCB layouts and efficient heat dissipation.
- Reliable Performance: Designed for commercial temperature range (-20°C to 70°C), ensuring stable operation in typical indoor environments.
