Elantec EL7563CRE-TZ
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $15.16 | $15.16 |
| 15+ | $3.49 | $52.35 |
| 25+ | $3.41 | $85.25 |
| 50+ | $3.22 | $161.00 |
| 100+ | $2.84 | $284.00 |
| N+ | $0.57 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Elantec |
| Product Series | |
| Packaging | Bulk | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 3V |
| Voltage - Input (Max) | 3.6V |
| Voltage - Output (Min/Fixed) | 1V |
| Voltage - Output (Max) | 2.5V |
| Current - Output | 4A |
| Frequency - Switching | Up to 1MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 28-HTSSOP |
The EL7563CRE-TZ is a high-current synchronous buck DC-DC converter from Elantec. It operates from a 3V to 3.6V input and provides an adjustable output from 1V to 2.5V, capable of delivering up to 4A. With a switching frequency up to 1MHz, it allows for compact external components. This converter is suitable for low-voltage, high-current applications in computing, networking, and industrial systems.
- High Output Current: Delivers up to 4A, ideal for powering modern digital loads.
- Adjustable Output: Output can be set from 1V to 2.5V, providing design flexibility.
- High Efficiency: Synchronous rectification reduces power loss, improving thermal performance.
- Compact Package: 28-TSSOP with exposed pad aids heat dissipation and saves board space.
Low-Voltage Logic Supplies
With a 3.3V input, the EL7563CRE-TZ can step down to 1.8V or 2.5V for DSPs and microcontrollers, providing up to 4A for high-performance processing.
Point-of-Load Converters
In systems with a 3.3V intermediate bus, this buck converter generates lower voltages (1V-2.5V) for FPGAs and ASICs, reducing distribution losses.
Portable Computing Devices
For handheld terminals powered by 3.3V rails, it supplies core voltages for application processors, ensuring efficient operation with its up-to-1MHz switching.
Networking Equipment
In routers and switches, it powers low-voltage logic from a 3.3V supply, delivering high current for packet processing engines.
Industrial Control Boards
For PLCs and motor controllers, it provides a stable 1.5V or 2.5V rail for sensors and communication interfaces, with a compact TSSOP package.
Test and Measurement
In benchtop instruments, it generates precise low-voltage rails for analog-to-digital converters and signal chains, maintaining low noise and ripple.
- Q: What type of converter is the EL7563CRE-TZ?
- A: It is a step-down (Buck) DC-DC converter.
- Q: What is the input voltage range?
- A: The input voltage range is 3V to 3.6V.
- Q: What is the output voltage range?
- A: The output is adjustable from 1V to 2.5V.
- Q: What is the maximum output current?
- A: It can deliver up to 4A of output current.
- Q: What is the switching frequency?
- A: The switching frequency is up to 1MHz.
- Q: What package is available?
- A: It comes in a 28-TSSOP exposed pad package.
