onsemi FAN2558MP13X
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.76 | $1.76 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | onsemi |
| Product Series | |
| Packaging | | |
| Output Configuration | Obsolete |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | - |
| Current - Output | 180mA |
| Current - Quiescent (Iq) | 150 μA |
| Current - Supply (Max) | - |
| PSRR | 50dB (100kHz) |
| Control Features | Enable, Power Good |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 6-VDFN Exposed Pad |
| Supplier Device Package | 6-DFN (2x2) |
| ROHS |  |
The Fairchild Semiconductor FAN2558MP13X is a fixed 1.3V low dropout linear regulator designed for low-voltage, high-performance applications. It delivers up to 180mA of output current with a low quiescent current of 150 µA. Its high-frequency PSRR of 50dB at 100kHz makes it excellent for filtering noise in digital and RF systems. The device is available in a compact 6-DFN (2x2) package.
- High-Frequency Noise Rejection: 50dB PSRR at 100kHz ensures clean power for high-speed digital and RF circuits.
- Low Quiescent Current: The 150 µA quiescent current is ideal for battery-powered applications.
- High Output Current: Capable of delivering 180mA, suitable for powering multiple low-voltage components.
- Compact DFN Package: The 6-DFN (2x2) package minimizes PCB footprint.
Low-Voltage Digital Core Power
The FAN2558MP13X provides a stable 1.3V supply for the latest low-voltage digital cores in FPGAs and ASICs, supporting up to 180mA of load current.
High-Frequency Noise Filtering
With 50dB PSRR at 100kHz, this regulator effectively filters high-frequency switching noise, making it ideal for powering PLLs and high-speed clock circuits.
Battery-Powered IoT Sensors
Its low quiescent current of 150 µA makes it suitable for battery-operated IoT sensors that require a low-voltage rail for their microcontroller and sensor interface.
Portable Audio Equipment
The low noise output and high-frequency PSRR ensure clean power for audio codecs and amplifiers, minimizing audible artifacts.
Compact Handheld Devices
The small 6-DFN (2x2) package is perfect for space-limited designs like smartwatches and fitness trackers, providing efficient power conversion.
- Q: What is the output voltage of the FAN2558MP13X?
- A: The fixed output voltage is 1.3V.
- Q: What is the maximum output current?
- A: The maximum output current is 180mA.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; please refer to the datasheet.
- Q: What is the dropout voltage?
- A: The dropout voltage is not specified in the provided data.
- Q: What is the quiescent current?
- A: The quiescent current is 150 µA.
- Q: What package is available?
- A: It comes in a 6-DFN (2x2) package.
