Connor Winfield FT9-TFC-112BPA
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $48.23 | $48.23 |
| 15+ | $46.71 | $700.65 |
| 25+ | $45.69 | $1,142.25 |
| 50+ | $43.15 | $2,157.50 |
| 100+ | $38.08 | $3,808.00 |
| N+ | $7.62 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Connor Winfield |
| Product Series | FT9-TFC |
| Packaging | Strip | |
| Type | Clock Frequency Translator, Clock Synchronizer, Jitter Attenuator |
| PLL | - |
| Input | LVCMOS |
| Output | LVCMOS |
| Number of Circuits | 1 |
| Ratio - Input:Output | 2:2 |
| Differential - Input:Output | - |
| Frequency - Max | 156.25MHz |
| Divider/Multiplier | - |
| Voltage - Supply | 3.13V ~ 3.47V |
| Operating Temperature | -40°C ~ 105°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | - |
| Supplier Device Package | - |
| ROHS |  |
The Connor Winfield FT9-TFC-112BPA is a versatile clock frequency translator, synchronizer, and jitter attenuator. It accepts an LVCMOS input and provides a clean LVCMOS output at 156.25MHz. With a single circuit and a wide operating temperature range of -40°C to 105°C, this device is ideal for telecom, networking, and industrial applications requiring precise timing and low jitter.
- High Precision: Delivers a stable 156.25MHz output, essential for high-speed data synchronization.
- Wide Temperature Range: Operates from -40°C to 105°C, suitable for harsh industrial environments.
- Jitter Attenuation: Improves signal quality by reducing phase noise and jitter in clock signals.
- Versatile Functionality: Combines frequency translation, synchronization, and jitter attenuation in one device.
Telecom Clock Synchronization
Use the FT9-TFC-112BPA to synchronize timing in telecom base stations, ensuring precise 156.25MHz clock alignment for reliable data transmission.
Networking Equipment Timing
Deploy in switches and routers to attenuate jitter and translate clock frequencies, maintaining signal integrity for high-speed Ethernet and optical networking.
Data Center Clock Distribution
Employ in servers and storage systems to generate stable, low-jitter clocks for processors and memory interfaces, improving overall system performance.
Broadcast Video Synchronization
Use for audio/video synchronization in broadcast equipment, providing a stable 156.25MHz reference to prevent frame drops and audio drift.
Industrial Automation Timing
Integrate into industrial controllers and PLCs for precise timing of control loops and synchronized data acquisition, enhancing operational accuracy.
Test and Measurement Instruments
Utilize in test equipment to provide a clean, stable clock source for accurate signal generation and analysis, ensuring measurement repeatability.
- Q: What type of device is the FT9-TFC-112BPA?
- A: It is a Clock Frequency Translator, Clock Synchronizer, and Jitter Attenuator from Connor Winfield.
- Q: Does this device support PLL?
- A: PLL support is not specified in the available technical data.
- Q: What are the input and output types?
- A: Both input and output types are LVCMOS, indicating single-ended signaling.
- Q: How many circuits does it have?
- A: It has 1 circuit.
- Q: What is the maximum frequency?
- A: The frequency is 156.25MHz.
- Q: What is the operating temperature range?
- A: It operates from -40°C to 105°C.
FT9-TFC-112BPA.pdf
