Infineon Technologies ICE2B765P2BKSA1
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | Dhs. 355,880.72 | Dhs. 355,880.72 |
| 15+ | Dhs. 344,642.38 | Dhs. 5,169,635.70 |
| 25+ | Dhs. 337,150.15 | Dhs. 8,428,753.75 |
| 50+ | Dhs. 318,419.59 | Dhs. 15,920,979.50 |
| 100+ | Dhs. 280,958.46 | Dhs. 28,095,846.00 |
| N+ | Dhs. 56,191.69 | Price Inquiry |
Request Quote / Inquiry
Infineon ICE2B765P2BKSA1 - CoolSET®F2 Offline Flyback Switching Controller
The ICE2B765P2BKSA1 from Infineon Technologies is a high-performance offline flyback switching controller from the CoolSET®F2 series, designed for isolated AC-DC power supply applications up to 240W. This integrated solution combines a 650V CoolMOS™ power MOSFET with advanced control circuitry, delivering exceptional efficiency and reliability for industrial, telecommunications, and consumer electronics applications.
Key Features & Benefits
- Integrated 650V Power Switch: Built-in CoolMOS™ technology reduces external component count and board space
- 240W Power Handling: Suitable for medium-power offline applications with excellent thermal performance
- 67kHz Switching Frequency: Optimized for transformer size reduction while maintaining low EMI
- Comprehensive Protection: Current limiting, over-voltage, over-temperature, over-load, and open-loop protection ensure safe operation
- Soft Start Function: Minimizes inrush current and stress on components during startup
- Wide Operating Range: -40°C to 150°C junction temperature for demanding environments
- Through-Hole Package: TO-220-6 format for easy assembly and excellent heat dissipation
Typical Applications
- AC-DC adapters and chargers
- Auxiliary power supplies for industrial equipment
- Telecom and networking power systems
- Home appliances and consumer electronics
- LED lighting drivers
Why Choose HQICKEY?
As an authorized distributor of Infineon Technologies, we provide 100% genuine components with full traceability, technical support, and global shipping. Our semiconductor specialists can assist with design-in resources, lifecycle management, and volume pricing for your project requirements.
Need assistance with design integration, alternative components, or volume pricing? Contact our technical team for expert support.
| Product attributes | Property Value |
| Manufacturer | Infineon Technologies |
| Product Series | CoolSET®F2 |
| Packaging | | |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Topology | Flyback |
| Voltage - Start Up | 13.5 V |
| Voltage - Supply (Vcc/Vdd) | 8.5V ~ 21V |
| Duty Cycle | 72% |
| Frequency - Switching | 67kHz |
| Power (Watts) | 240 W |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage |
| Control Features | Soft Start |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-6 Formed Leads |
| Supplier Device Package | PG-TO220-6-47 |
ICE2B765P2BKSA1.pdf
