Infineon Technologies ICE3A3565PBKSA1
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | Dhs. 355,880.72 | Dhs. 355,880.72 |
| 15+ | Dhs. 344,642.38 | Dhs. 5,169,635.70 |
| 25+ | Dhs. 337,150.15 | Dhs. 8,428,753.75 |
| 50+ | Dhs. 318,419.59 | Dhs. 15,920,979.50 |
| 100+ | Dhs. 280,958.46 | Dhs. 28,095,846.00 |
| N+ | Dhs. 56,191.69 | Price Inquiry |
Request Quote / Inquiry
Infineon ICE3A3565PBKSA1 CoolSET™ F3 Offline Flyback Switching Controller
The ICE3A3565PBKSA1 from Infineon Technologies is a high-performance offline flyback switching controller featuring integrated CoolMOS™ technology. This advanced power IC delivers reliable 170W power conversion with exceptional efficiency and comprehensive protection features, making it ideal for industrial power supplies, LED drivers, and consumer electronics applications.
Key Features & Benefits:
- High Voltage Capability: 650V breakdown voltage for robust performance in demanding applications
- Integrated Switch: Built-in CoolMOS switch reduces component count and board space
- Wide Operating Range: 8.5V to 21V supply voltage with 15V start-up
- Efficient Switching: 100kHz switching frequency with 72% duty cycle for optimal power conversion
- Comprehensive Protection: Current limiting, over-temperature, over-voltage, over-load, and open-loop protection
- Soft Start Control: Reduces inrush current and extends component lifespan
- Industrial Temperature Range: -25°C to 130°C (TJ) for reliable operation in harsh environments
- Standard Package: TO-220-6 through-hole mounting for easy integration
Applications:
Perfect for AC/DC power supplies, battery chargers, LED lighting drivers, industrial control systems, telecommunications equipment, and consumer electronics requiring efficient isolated power conversion.
Why Choose ICE3A3565PBKSA1? This controller combines Infineon's proven CoolMOS and CoolSET technologies to deliver superior efficiency, reliability, and protection in a compact package. The integrated design simplifies your power supply development while ensuring long-term performance and compliance with international safety standards.
| Product attributes | Property Value |
| Manufacturer | Infineon Technologies |
| Product Series | CoolMOS™, CoolSET™F3 |
| Packaging | | |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Topology | Flyback |
| Voltage - Start Up | 15 V |
| Voltage - Supply (Vcc/Vdd) | 8.5V ~ 21V |
| Duty Cycle | 72% |
| Frequency - Switching | 100kHz |
| Power (Watts) | 170 W |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage |
| Control Features | Soft Start |
| Operating Temperature | -25°C ~ 130°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-6 Formed Leads |
| Supplier Device Package | PG-TO220-6-47 |
ICE3A3565PBKSA1.pdf
