Infineon ICE3B5065PBKSA1 CoolSET™ F3 Offline Switcher IC
The ICE3B5065PBKSA1 from Infineon Technologies is a high-performance offline switcher IC from the CoolSET™ F3 series, designed for isolated flyback power supply applications up to 220W. This integrated solution combines a 650V CoolMOS™ power MOSFET with a current mode controller, delivering exceptional efficiency and reliability for AC/DC power conversion.
Key Features & Benefits
- High Integration: Integrated 650V power switch reduces component count and board space
- Wide Input Range: 8.5V to 21V supply voltage with 15V startup capability
- Optimized Performance: 67kHz switching frequency with 72% maximum duty cycle
- Comprehensive Protection: Built-in current limiting, overload, over-temperature, over-voltage, and open-loop protection
- Soft Start Control: Minimizes inrush current and stress on components
- Extended Temperature Range: -25°C to 130°C junction temperature operation
- Reliable Package: Through-hole TO-220-6 with formed leads for easy assembly
Typical Applications
- AC/DC power supplies for consumer electronics
- Industrial power conversion systems
- Telecom and networking equipment
- LED lighting drivers
- Auxiliary power supplies
Why Choose ICE3B5065PBKSA1?
This CoolSET F3 IC offers design engineers a proven, cost-effective solution for medium-power offline applications. The integrated approach simplifies design, reduces BOM costs, and accelerates time-to-market while maintaining high efficiency and robust protection features essential for reliable power supply operation.
| Product attributes | Property Value |
| Manufacturer | Infineon Technologies |
| Product Series | CoolMOS™, CoolSET™F3 |
| Packaging | | |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Topology | Flyback |
| Voltage - Start Up | 15 V |
| Voltage - Supply (Vcc/Vdd) | 8.5V ~ 21V |
| Duty Cycle | 72% |
| Frequency - Switching | 67kHz |
| Power (Watts) | 220 W |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage |
| Control Features | Soft Start |
| Operating Temperature | -25°C ~ 130°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-6 Formed Leads |
| Supplier Device Package | PG-TO220-6-47 |
