Power Integrations IGD515EI
Regular price
$168.33
Regular price
$177.19
Sale price
$168.33
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $168.33 | $168.33 |
| 15+ | $163.01 | $2,445.15 |
| 25+ | $159.47 | $3,986.75 |
| 50+ | $150.61 | $7,530.50 |
| 100+ | $132.89 | $13,289.00 |
| N+ | $26.58 | Price Inquiry |
Shipping calculated at checkout.
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Power Integrations |
| Product Series | SCALE™-1 |
| Packaging | Bulk | |
| Driven Configuration | High-Side or Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | IGBT, MOSFET (N-Channel, P-Channel) |
| Voltage - Supply | 12V ~ 16V |
| Logic Voltage - VIL, VIH | 0.9V, 3.8V |
| Current - Peak Output (Source, Sink) | 15A, 15A |
| Input Type | - |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 40ns, 40ns |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | Module |
| Supplier Device Package | Module |
IGD515EI.pdf
×
