National Semiconductor LM2576HVSX-12
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $25.20 | $25.20 |
| 15+ | $5.80 | $87.00 |
| 25+ | $5.67 | $141.75 |
| 50+ | $5.36 | $268.00 |
| 100+ | $4.73 | $473.00 |
| N+ | $0.95 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | National Semiconductor |
| Product Series | SIMPLE SWITCHER® |
| Packaging | Bulk | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4V |
| Voltage - Input (Max) | 60V |
| Voltage - Output (Min/Fixed) | 12V |
| Voltage - Output (Max) | - |
| Current - Output | 3A |
| Frequency - Switching | 52kHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA |
| Supplier Device Package | TO-263 (DDPAK-5) |
| ROHS |  |
The LM2576HVSX-12 from National Semiconductor is a robust step-down DC-DC converter delivering a fixed 12V output from a 4V to 60V input. It supports up to 3A of load current at a 52kHz switching frequency, offering a simple, high-efficiency solution for automotive, industrial, and telecom applications. The TO-263-6 (D2PAK) package ensures excellent thermal performance in demanding environments.
