Texas Instruments LM2594HVN-12/NOPB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $5.64 | $5.64 |
| 15+ | $5.46 | $81.90 |
| 25+ | $5.35 | $133.75 |
| 50+ | $5.05 | $252.50 |
| 100+ | $4.46 | $446.00 |
| N+ | $0.89 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | SIMPLE SWITCHER® |
| Packaging | Tube | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 60V |
| Voltage - Output (Min/Fixed) | 12V |
| Voltage - Output (Max) | - |
| Current - Output | 500mA |
| Frequency - Switching | 150kHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
| ROHS |  |
The LM2594HVN-12/NOPB from Texas Instruments is a simple and reliable step-down (Buck) switching regulator with a fixed 12V output. It features a wide input voltage range from 4.5V to 60V, making it ideal for high-voltage industrial and automotive applications. Capable of delivering 500mA of output current, it operates at a 150kHz switching frequency. The 8-DIP package is easy to use and solder, making it suitable for through-hole PCB designs. This converter offers a robust and cost-effective solution for generating a regulated 12V rail.
- High 60V Input Voltage: Safely handles 48V industrial rails and automotive transients without external protection.
- Simple Fixed 12V Output: Requires minimal external components, simplifying design and BOM.
- Proven, Rugged Design: Based on the popular LM259x family, known for reliability and ease of use.
- 150kHz Switching Frequency: Well-suited for noise-sensitive applications and compatible with standard components.
- Through-Hole 8-DIP Package: Easy to prototype and assemble, ideal for industrial control boards.
High-Voltage Industrial Supplies
With a 60V input rating, it can step down 48V industrial rails to 12V for sensors, relays, and control circuits, offering excellent margin.
Automotive 24V Systems
Regulates 24V truck or bus electrical systems down to 12V for aftermarket electronics, telematics, and lighting, handling voltage spikes.
HVAC & Building Automation
Converts 24VAC rectified to DC or 48V DC bus voltages to a stable 12V for thermostats, actuators, and zone controllers.
Battery-Powered Equipment
Efficiently steps down high-voltage battery packs (e.g., 36V-48V) to 12V for power tools, e-bikes, and portable instruments.
Distributed Power Systems
Provides a simple, low-cost solution for generating a local 12V rail from a high-voltage backplane in industrial and telecom equipment.
Appliance Control Boards
Powers microcontrollers and display drivers in large appliances that use high-voltage DC buses for motors and heaters.
- Q: What type of converter is the LM2594HVN-12/NOPB?
- A: It is a Buck (step-down) DC-DC converter.
- Q: What is the input voltage range?
- A: The input voltage range is from 4.5V to 60V.
- Q: What is the fixed output voltage?
- A: It provides a fixed 12V output.
- Q: What is the maximum output current?
- A: It can deliver up to 500mA of output current.
- Q: What is the switching frequency?
- A: The switching frequency is 150kHz.
- Q: What package is available?
- A: It is available in an 8-DIP package.
