National Semiconductor LM9076S-5.0
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $8.08 | $8.08 |
| 15+ | $1.86 | $27.90 |
| 25+ | $1.82 | $45.50 |
| 50+ | $1.72 | $86.00 |
| 100+ | $1.52 | $152.00 |
| N+ | $0.30 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | National Semiconductor |
| Product Series | |
| Packaging | Bulk | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.25V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 45 µA |
| Current - Supply (Max) | 4.5 mA |
| PSRR | 60dB (120kHz) |
| Control Features | Reset |
| Protection Features | Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA |
| Supplier Device Package | DDPAK/TO-263-5 |
| ROHS |  |
The LM9076S-5.0 is a low dropout linear regulator from National Semiconductor, delivering a fixed 5V output with up to 150mA of current. Its ultra-low quiescent current of 45 µA and low dropout voltage of 0.25V make it an excellent choice for battery-powered and automotive applications. The DDPAK/TO-263-5 package ensures robust thermal performance, while 60dB PSRR at 120kHz provides clean, stable power for sensitive electronics.
- Extended Battery Life: Ultra-low 45 µA quiescent current minimizes standby power consumption, ideal for always-on applications.
- High Efficiency at Low Dropout: 0.25V dropout at 150mA allows operation with minimal input-to-output voltage difference, reducing power dissipation.
- Excellent Noise Rejection: 60dB PSRR at 120kHz ensures stable output for noise-sensitive analog and RF circuits.
- Robust Thermal Package: DDPAK/TO-263-5 package dissipates heat effectively, supporting reliable operation in high-temperature environments.
Automotive Power Supplies
The LM9076S-5.0's low quiescent current (45 µA) and 5V output make it ideal for always-on automotive systems like body control modules and sensor interfaces, minimizing battery drain when the vehicle is off.
Battery-Powered Instruments
With a dropout of only 0.25V at 150mA, this regulator maximizes battery life in portable instruments by allowing operation close to the battery's end-of-life voltage.
Industrial Control Systems
The DDPAK/TO-263-5 package provides excellent thermal dissipation for industrial controllers that require a stable 5V rail for logic and analog circuits, with 60dB PSRR at 120kHz to reject noise.
Telecom Equipment
For telecom line cards, the LM9076S-5.0 delivers clean 5V power with high ripple rejection, ensuring reliable operation of communication processors and interface ICs.
Medical Monitoring Devices
Low quiescent current and stable output make this LDO suitable for portable medical monitors, where long battery life and consistent voltage are critical for patient safety.
IoT Edge Nodes
In IoT sensors, the 45 µA quiescent current extends battery life between data transmissions, while the 5V output powers microcontrollers and wireless transceivers efficiently.
- Q: What is the output voltage of the LM9076S-5.0?
- A: The LM9076S-5.0 provides a fixed 5V output.
- Q: What is the maximum output current?
- A: It can deliver up to 150mA of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; please refer to the datasheet for full specifications.
- Q: What is the dropout voltage?
- A: The dropout voltage is typically 0.25V at 150mA load.
- Q: What is the quiescent current?
- A: The quiescent current is very low at 45 µA, making it suitable for battery-powered applications.
- Q: What package is available?
- A: It comes in a DDPAK/TO-263-5 package.
