National Semiconductor LM9076S-5.0/NOPB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $6.24 | $6.24 |
| 15+ | $1.44 | $21.60 |
| 25+ | $1.40 | $35.00 |
| 50+ | $1.33 | $66.50 |
| 100+ | $1.17 | $117.00 |
| N+ | $0.23 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | National Semiconductor |
| Product Series | |
| Packaging | Bulk | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.25V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 45 µA |
| Current - Supply (Max) | 4.5 mA |
| PSRR | 60dB (120kHz) |
| Control Features | Reset |
| Protection Features | Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA |
| Supplier Device Package | TO-263 (DDPAK-5) |
| ROHS |  |
The LM9076S-5.0/NOPB is a low dropout linear regulator designed to provide a fixed 5V output. It delivers up to 150mA of current with a low dropout voltage of 0.25V. The regulator features a low quiescent current of 45 µA, making it efficient for battery-powered and always-on applications. With 60dB PSRR at 120kHz, it offers good noise rejection for sensitive electronics. Housed in a TO-263 (DDPAK-5) package, it is a robust and reliable power management solution.
- Low Power Consumption: The 45 µA quiescent current minimizes power loss, ideal for battery-operated devices.
- Low Dropout Voltage: The 0.25V dropout at 150mA allows operation with a small input-to-output voltage difference, improving efficiency.
- Good High-Frequency Noise Rejection: 60dB PSRR at 120kHz helps filter high-frequency noise, protecting sensitive circuits.
- Robust Package: The TO-263 package provides excellent thermal performance and is suitable for automotive and industrial environments.
Automotive Electronics
Ideal for powering sensors, microcontrollers, and interface circuits in automotive systems that require a stable 5V supply from a battery.
Industrial Control Systems
Provides a reliable 5V rail for PLCs, industrial sensors, and control logic, ensuring consistent operation in demanding environments.
Battery-Powered Equipment
The low 45 µA quiescent current makes it suitable for battery-operated devices where power conservation is critical.
Microcontroller and Logic Power
Its 150mA output is sufficient for many 5V microcontrollers and associated logic, providing a clean and stable supply.
Noise-Isolated Analog Supplies
With 60dB PSRR at 120kHz, it helps isolate sensitive analog circuits from high-frequency digital noise on the power rail.
- Q: What is the output voltage of the LM9076S-5.0/NOPB?
- A: The fixed output voltage is 5V.
- Q: What is the maximum output current?
- A: It can deliver up to 150mA of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; refer to the datasheet for full specifications.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.25V at a 150mA load.
- Q: What is the quiescent current?
- A: The quiescent current is 45 µA.
- Q: What package is available?
- A: It is available in a TO-263 (DDPAK-5) package.
