Power Integrations LNK6418E
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Power Integrations |
| Product Series | LinkSwitch™-3 |
| Packaging | | |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 725V |
| Topology | Flyback |
| Voltage - Start Up | - |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 55% |
| Frequency - Switching | Up to 85kHz |
| Power (Watts) | 10 W |
| Fault Protection | Current Limiting, Open Loop, Over Temperature, Short Circuit |
| Control Features | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads |
| Supplier Device Package | eSIP-7C |
| ROHS |  |
The Power Integrations LNK6418E is an isolated Flyback offline switcher from the LinkSwitch™-3 series with an integrated power switch. It delivers up to 10 W with a 725V breakdown rating, up to 85kHz switching frequency, and 55% maximum duty cycle. Comprehensive fault protection includes current limiting, open loop, over temperature, and short circuit safeguards. Housed in a 7-SSIP package with exposed pad, it operates across a -40°C to 150°C junction temperature range.
- Integrated power switch reduces external component count and simplifies Flyback design.
- 725V breakdown voltage provides headroom for universal offline AC input.
- Up to 10 W output with up to 85kHz switching supports compact isolated supplies.
- Comprehensive fault protection (current limiting, open loop, over temperature, short circuit) enhances reliability.
- Wide -40°C to 150°C junction temperature range suits demanding thermal environments.
Compact AC-DC Adapters
The LNK6418E integrates the power switch and controller in a Flyback topology, delivering up to 10 W for space-constrained chargers and adapters. The 725V breakdown rating provides margin for universal AC input.
Standby & Auxiliary Supplies
With up to 85kHz switching and 55% max duty cycle, this isolated Flyback switcher suits auxiliary bias supplies requiring galvanic isolation and reliable regulation.
Home Appliance Power
Built-in current limiting, open loop, over temperature, and short circuit protection make the LNK6418E well suited for appliance control boards operating in demanding thermal environments up to 150°C junction temperature.
Industrial Control Modules
The 7-SSIP exposed-pad package aids thermal dissipation, supporting continuous isolated power delivery in industrial instrumentation and metering designs.
