Texas Instruments LP3985ITL-2.6/NOPB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.62 | $0.62 |
| 15+ | $0.60 | $9.00 |
| 25+ | $0.59 | $14.75 |
| 50+ | $0.55 | $27.50 |
| 100+ | $0.49 | $49.00 |
| N+ | $0.10 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Marketplace | Cut Tape (CT) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 2.6V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.1V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 150 µA |
| Current - Supply (Max) | 250 µA |
| PSRR | 50dB ~ 40dB (1kHz ~ 10kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 5-WFBGA, DSBGA |
| Supplier Device Package | 5-DSBGA (1.41x1.08) |
The LP3985ITL-2.6/NOPB from Texas Instruments is an ultra-small, low dropout linear regulator offering a fixed 2.6V output at up to 150mA. Housed in a 5-DSBGA package measuring just 1.41x1.08mm, it is designed for space-constrained portable electronics. With a dropout voltage of only 0.1V at full load and a quiescent current of 150µA, it delivers excellent efficiency for battery-powered applications while maintaining stable output for sensitive loads.
- Minimal PCB Footprint: 5-DSBGA package (1.41x1.08mm) enables ultra-compact product designs.
- Low Dropout Operation: 0.1V dropout at 150mA extends battery life by allowing operation from low input voltages.
- Stable for Analog Loads: 50dB PSRR at 1kHz reduces supply noise for audio and sensor circuits.
- Low Power Consumption: 150µA quiescent current is ideal for always-on applications.
Ultra-Compact Wearable Devices
The 5-DSBGA package (1.41x1.08mm) is among the smallest available, making the LP3985ITL-2.6/NOPB perfect for smartwatches, fitness bands, and hearing aids where PCB area is extremely limited.
Portable Medical Monitors
With 150µA quiescent current and 0.1V dropout, this regulator supports continuous glucose monitors and pulse oximeters that run on coin cells, extending operational life between replacements.
Bluetooth Low Energy Sensors
BLE beacons and environmental sensors benefit from the stable 2.6V rail, ensuring consistent RF output power and reliable wireless communication in IoT mesh networks.
Camera Module Power
Compact camera modules in smartphones and laptops require clean, stable voltage for image sensors; the LP3985ITL-2.6/NOPB delivers with 50dB PSRR at 1kHz.
MEMS Microphone Bias
MEMS microphones need a low-noise supply; this LDO's low dropout and moderate PSRR help maintain audio signal integrity in voice-controlled devices.
FPGA Core Voltage (Low Power)
For small, low-power FPGAs or CPLDs requiring a 2.6V core, this regulator provides a compact, efficient solution in prototyping and production designs.
- Q: What is the output voltage?
- A: The LP3985ITL-2.6/NOPB provides a fixed 2.6V output.
- Q: What is the maximum current rating?
- A: It can supply up to 150mA of output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; consult the datasheet.
- Q: What is the dropout voltage?
- A: Dropout is very low at 0.1V typical at 150mA load.
- Q: What is the quiescent current?
- A: Quiescent current is 150µA.
- Q: What package is this available in?
- A: It comes in a 5-DSBGA package measuring 1.41x1.08mm.
