Texas Instruments LP5990TMX-3.6/NOPB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.66 | $0.66 |
| 15+ | $0.63 | $9.45 |
| 25+ | $0.62 | $15.50 |
| 50+ | $0.59 | $29.50 |
| 100+ | $0.52 | $52.00 |
| N+ | $0.10 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 3.6V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.25V @ 200mA |
| Current - Output | 200mA |
| Current - Quiescent (Iq) | 75 µA |
| Current - Supply (Max) | - |
| PSRR | 55dB (10kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-WFBGA, DSBGA |
| Supplier Device Package | 4-DSBGA |
| ROHS |  |
The LP5990TMX-3.6/NOPB is a fixed 3.6V LDO linear regulator from Texas Instruments, delivering up to 200mA. With a low dropout of 0.25V and a quiescent current of 75 µA, it offers efficient power conversion for battery-operated devices. The compact 4-DSBGA package is designed for space-constrained applications requiring stable voltage regulation.
- Efficient Power Conversion: Low 0.25V dropout at 200mA maximizes headroom, improving efficiency in battery-powered designs.
- Compact Footprint: 4-DSBGA package saves critical board space in miniaturized electronics.
- Stable Output: 55dB PSRR at 10kHz filters switching noise, ensuring clean power for sensitive loads.
- Low Power Consumption: 75 µA quiescent current reduces standby drain, extending battery life.
Portable Audio Players
The 3.6V output and 55dB PSRR at 10kHz provide clean power for audio DACs and amplifiers, reducing distortion and improving sound quality in compact media players.
Wireless Headsets
Low dropout (0.25V) allows efficient operation from a single Li-ion cell (3.7V nominal), while the 200mA capacity supports Bluetooth audio SoCs and sensors.
Digital Cameras
Stable 3.6V rail powers image sensors and processing ICs, with the 4-DSBGA package fitting into tight camera module layouts.
Wearable Fitness Trackers
The 75 µA quiescent current helps extend battery life in always-on wearable devices, while the small package minimizes PCB footprint.
Industrial Handheld Tools
Reliable 3.6V output for microcontroller and display interfaces in rugged handheld instruments, with thermal performance suited for moderate loads.
Set-Top Boxes
Provides a clean 3.6V rail for tuner and demodulator circuits, with PSRR reducing interference from digital switching noise.
- Q: What is the output voltage of the LP5990TMX-3.6?
- A: This LDO provides a fixed 3.6V output.
- Q: What is the maximum output current?
- A: It can supply up to 200mA of output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; consult the datasheet.
- Q: What is the dropout voltage?
- A: Dropout is typically 0.25V at a 200mA load.
- Q: What is the quiescent current?
- A: Quiescent current is 75 µA.
- Q: What package is available?
- A: It is available in a 4-DSBGA package.
