Linear Technology LT1766EGN-5#TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $34.64 | $34.64 |
| 15+ | $7.97 | $119.55 |
| 25+ | $7.79 | $194.75 |
| 50+ | $7.36 | $368.00 |
| 100+ | $6.50 | $650.00 |
| N+ | $1.30 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Linear Technology |
| Product Series | |
| Packaging | Bulk | |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 5.5V |
| Voltage - Input (Max) | 60V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Current - Output | 1.5A |
| Frequency - Switching | 200kHz |
| Synchronous Rectifier | No |
| Operating Temperature | - |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SSOP |
The LT1766EGN-5#TR from Linear Technology is a robust step-down switching regulator designed for high-voltage applications. It accepts an input voltage from 5.5V to 60V and provides a fixed 5V output with up to 1.5A of current. The 200kHz fixed switching frequency balances efficiency with external component size. Packaged in a 16-pin SSOP, this IC is ideal for automotive, industrial, and telecom power supplies requiring wide input tolerance and reliable 5V delivery.
- Wide Input Voltage: 5.5V to 60V handles automotive load dumps and industrial 48V rails.
- High Efficiency: Internal 1.5A switch with low saturation voltage minimizes power loss.
- Fixed 200kHz Frequency: Simplifies EMI filtering and allows small inductors.
- Robust Protection: Built-in thermal shutdown and current limiting enhance system reliability.
Automotive Power Systems
With a 5.5V to 60V input range, the LT1766EGN-5#TR handles 12V/24V automotive buses, including load-dump transients up to 60V, providing a stable 5V rail for ECUs, sensors, and infotainment systems.
Industrial 48V Power Supplies
In factory automation and process control, this buck converter steps down 48V industrial buses to 5V for PLCs, motor drives, and HMI panels, with robust protection against voltage spikes.
Telecom and Networking
For telecom equipment powered by 48V backplanes, the LT1766EGN-5#TR delivers 1.5A at 5V for line cards, switches, and routers, ensuring reliable operation in high-voltage environments.
Avionics and Defense
In avionics systems with 28V supplies, this regulator provides a regulated 5V output for flight control computers and navigation equipment, meeting stringent reliability standards.
Renewable Energy Systems
For solar and wind power inverters with DC buses up to 60V, the LT1766EGN-5#TR powers control circuits and communication interfaces, maintaining efficiency across varying input voltages.
- Q: What type of converter is the LT1766EGN-5#TR?
- A: It is a step-down (Buck) switching regulator.
- Q: What is the input voltage range?
- A: The input voltage range is from 5.5V to 60V.
- Q: What is the output voltage?
- A: The fixed output voltage is 5V.
- Q: What is the maximum output current?
- A: It can deliver up to 1.5A of continuous output current.
- Q: What is the switching frequency?
- A: The switching frequency is fixed at 200kHz.
- Q: What package is available?
- A: It comes in a 16-pin SSOP package (0.154 inch width).
