Analog Devices Inc. LT3065IMSE-1.5#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $14.72 | $14.72 |
| 15+ | $7.04 | $105.60 |
| 25+ | $6.89 | $172.25 |
| 50+ | $6.50 | $325.00 |
| 100+ | $5.74 | $574.00 |
| N+ | $1.15 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 45V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.51V @ 500mA |
| Current - Output | 500mA |
| Current - Quiescent (Iq) | 110 µA |
| Current - Supply (Max) | 25 mA |
| PSRR | 78dB (120Hz) |
| Control Features | Current Limit, Enable, Power Good, Soft Start |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 12-TSSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 12-MSOP-EP |
| ROHS |  |
The LT3065IMSE-1.5#PBF is a precision low dropout linear regulator from Linear Technology, offering a fixed 1.5V output with up to 500mA current capability. Featuring an ultra-low 110µA quiescent current and exceptional 78dB PSRR at 120Hz, it delivers clean, stable power for noise-sensitive applications. The compact 12-MSOP-EP package and low 0.51V dropout voltage make it an efficient solution for space-constrained, battery-powered designs.
- Superior Noise Rejection: 78dB PSRR at 120Hz ensures clean output for sensitive audio and RF circuits.
- Minimal Power Loss: Low 0.51V dropout at 500mA maximizes efficiency in low-headroom applications.
- Extended Battery Life: 110µA quiescent current significantly reduces standby power consumption.
- Compact Footprint: 12-MSOP-EP package is ideal for space-constrained PCB designs.
Low-Voltage Digital Core Supplies
Many modern microcontrollers and FPGAs operate at 1.5V core voltages. The LT3065IMSE-1.5#PBF provides a stable, low-noise 1.5V rail with up to 500mA, ensuring reliable operation of digital logic.
Battery-Powered Wearables
With a low 110µA quiescent current, this LDO is perfect for wearable devices where battery life is critical. The 1.5V output efficiently powers low-voltage sensors and MCUs.
High-Performance Audio Equipment
The 78dB PSRR at 120Hz ensures that power supply noise does not contaminate audio signals, making this regulator ideal for powering DACs and audio codecs requiring a clean 1.5V reference.
Industrial Control Systems
The wide input voltage range and robust thermal package make it suitable for industrial environments where supply voltages may vary, providing a consistent 1.5V output for control logic.
Telecommunications Infrastructure
For networking equipment requiring low-voltage rails, the LT3065IMSE-1.5 delivers clean power with minimal dropout, ensuring stable operation even under heavy load transients.
Precision Analog Front-Ends
The combination of low noise and high PSRR makes this regulator an excellent choice for powering analog front-end circuits in data acquisition systems that require a precise 1.5V supply.
- Q: What is the output voltage of the LT3065IMSE-1.5#PBF?
- A: The fixed output voltage is 1.5V.
- Q: What is the maximum output current?
- A: It can deliver up to 500mA of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is from 1.5V up to 45V (not explicitly stated, but typical for LT3065 family; verify with datasheet).
- Q: What is the dropout voltage?
- A: The dropout voltage is typically 0.51V at 500mA load.
- Q: What is the quiescent current?
- A: The quiescent current is a low 110µA, making it suitable for battery-powered applications.
- Q: What package is available?
- A: It comes in a 12-lead MSOP with exposed pad (12-MSOP-EP).
