LTC1294CCN#PBF - 12-Bit 8-Channel Data Acquisition System IC
The LTC1294CCN#PBF from Analog Devices is a high-performance 12-bit, 8-channel analog-to-digital converter (ADC) engineered for precision data acquisition in demanding industrial, automotive, telecommunications, and medical electronics applications. Combining 12-bit resolution with 46.5kSPS sampling rate and flexible dual ±5V supply operation, this versatile IC delivers reliable, accurate signal conversion for multi-channel measurement and control systems.
Key Features & Technical Advantages
- 12-bit resolution – Ensures precise analog-to-digital conversion with 4096 discrete levels for accurate signal representation
- 8 independent input channels – Enables simultaneous multi-point sensing and monitoring in a single compact device, reducing component count and board space
- 46.5kSPS sampling rate – Provides fast data capture suitable for dynamic signal acquisition and real-time control applications
- Dual serial and parallel data interfaces – Offers flexible integration with microcontrollers, DSPs, and embedded processors for seamless system design
- Through-hole DIP-20 package – Simplifies prototyping, manual assembly, and field replacement in industrial environments
- 0°C to 70°C commercial operating temperature range – Suitable for standard commercial and light industrial environments
- Dual ±5V supply operation – Compatible with legacy and modern mixed-signal systems
- RoHS compliant – Meets environmental regulations and global compliance standards for lead-free manufacturing
Target Applications & Use Cases
The LTC1294CCN#PBF is ideally suited for:
- Multi-channel sensor signal conditioning and acquisition systems
- Industrial process control and monitoring equipment
- Test and measurement instrumentation requiring precision analog input
- Multi-channel data loggers for environmental, automotive, and medical diagnostics
- Embedded control systems with analog feedback loops
- Battery management systems and power monitoring applications
- Laboratory and R&D prototyping platforms
Why Choose LTC1294CCN#PBF?
Analog Devices' LTC1294 family is renowned for long lifecycle support, proven reliability in harsh environments, and comprehensive technical documentation. The through-hole DIP-20 package ensures ease of prototyping and field serviceability, while the dual interface options provide maximum design flexibility for legacy and modern systems alike.
For detailed electrical characteristics, timing diagrams, pin configurations, and application circuits, please refer to the official Analog Devices LTC1294 datasheet.
Ordering & Availability
The LTC1294CCN#PBF is available for immediate shipment. All units are factory-sealed, RoHS compliant, and backed by our quality guarantee. Contact us for volume pricing, custom packaging, or technical support.
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Type | Data Acquisition System (DAS), ADC |
| Number of Channels | 8 |
| Resolution (Bits) | 12 b |
| Sampling Rate (Per Second) | 46.5k |
| Data Interface | Serial, Parallel |
| Voltage Supply Source | Dual ± |
| Voltage - Supply | ±5V, 5V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Grade | - |
| Qualification | - |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Supplier Device Package | 20-PDIP |
| ROHS |  |
