Analog Devices Inc. LTC2326IMS-16#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $32.57 | $32.57 |
| 15+ | $31.54 | $473.10 |
| 25+ | $30.85 | $771.25 |
| 50+ | $29.14 | $1,457.00 |
| 100+ | $25.71 | $2,571.00 |
| N+ | $5.14 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 250k |
| Number of Inputs | 1 |
| Input Type | Pseudo-Differential |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 16-TFSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 16-MSOP |
| ROHS |  |
The LTC2326IMS-16#PBF is a 16-bit, single-channel ADC from Analog Devices, offering a maximum sampling rate of 250k SPS. Its SPI interface simplifies integration with digital systems, while the S/H-ADC architecture ensures accurate sampling of analog signals. With support for external or internal references and a compact 16-TFSOP package, this converter is well-suited for portable instruments, industrial controls, and automotive sensor applications.
- Compact 16-TFSOP Package: Saves board space in space-constrained designs like wearables and portable tools.
- SPI Interface: Simplifies connection to standard microcontrollers, reducing design complexity.
- 16-Bit Resolution at 250k SPS: Offers excellent accuracy for high-speed industrial and medical measurements.
- Wide Temperature Range (-40°C to 85°C): Suitable for automotive and industrial environments.
Portable Instrumentation
The small 16-TFSOP package and SPI interface make the LTC2326IMS-16#PBF ideal for handheld multimeters and portable data loggers where space is limited.
Industrial Process Control
With 16-bit resolution and 250k SPS, this ADC accurately digitizes 4-20mA loop signals in PLCs and distributed control systems, ensuring precise process regulation.
Medical Wearable Devices
The low-power, single-channel design supports continuous monitoring of vital signs like heart rate or oxygen saturation in battery-operated wearables.
Automotive Sensor Interfaces
Operating from -40°C to 85°C, it can handle engine control unit (ECU) sensor signals such as temperature or pressure with high fidelity.
Laboratory Test Equipment
The SPI interface and high accuracy make it suitable for benchtop multimeters and spectrum analyzers requiring reliable, repeatable measurements.
- Q: What is the LTC2326IMS-16#PBF?
- A: It is a 16-bit, single-channel analog-to-digital converter with S/H-ADC architecture and SPI interface.
- Q: What is the resolution of this ADC?
- A: The resolution is 16 bits, providing high precision for measurement applications.
- Q: What is the sampling rate?
- A: The maximum sampling rate is 250k SPS.
- Q: How many channels does it have?
- A: It has 1 input channel.
- Q: What interface does it support?
- A: It uses a SPI serial interface, which is easy to connect to most microcontrollers.
- Q: What is the package type?
- A: It comes in a 16-TFSOP (0.118", 3.00mm Width) package, operating from -40°C to 85°C.
