Analog Devices Inc. LTC2378IMS-20#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $60.88 | $60.88 |
| 15+ | $58.95 | $884.25 |
| 25+ | $57.67 | $1,441.75 |
| 50+ | $54.47 | $2,723.50 |
| 100+ | $48.06 | $4,806.00 |
| N+ | $9.61 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Number of Bits | 20 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 2.375V ~ 2.625V |
| Voltage - Supply, Digital | 2.375V ~ 2.625V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 16-TFSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 16-MSOP |
| ROHS |  |
The LTC2378IMS-20#PBF is a 20-bit, 1 MSPS analog-to-digital converter (ADC) from Analog Devices, engineered for high-precision signal conversion. It features a single channel with a sample-and-hold architecture, ensuring accurate sampling of analog inputs. The device uses a SPI interface for straightforward digital communication. Packaged in a compact 16-TFSOP (3.00mm width), it is designed for space-constrained applications. With an operating temperature range of -40°C to 85°C, it delivers reliable performance in industrial and automotive environments where precision and durability are essential.
- 20-Bit High Resolution: Offers excellent dynamic range, making it ideal for applications requiring fine measurement granularity.
- 1 MSPS Speed: Provides fast conversion without sacrificing accuracy, suitable for real-time control systems.
- SPI Interface: Ensures easy integration with standard digital processors and reduces pin count.
- Compact TFSOP Package: Enables high-density board designs, perfect for portable and miniaturized devices.
Precision Data Acquisition
The 20-bit resolution at 1 MSPS is ideal for high-accuracy data acquisition systems that require both speed and precision, such as vibration analysis or high-end audio testing.
Industrial Process Control
In chemical plants or refineries, the ADC can accurately digitize signals from pressure and temperature transmitters, enabling precise control loops and reducing waste.
Portable Instrumentation
The small TFSOP package and low power consumption make it suitable for battery-powered handheld multimeters and field calibrators that need high accuracy.
Automotive Sensor Interfaces
For engine control units, the 20-bit resolution helps in accurately measuring exhaust gas sensors or battery voltage, improving fuel efficiency and emissions control.
Seismic Monitoring
In geophysical equipment, the high resolution allows for detecting very small ground movements, essential for earthquake early warning systems.
Laboratory Balances
The precision of 20 bits is sufficient for analytical balances, providing stable and repeatable weight measurements in research and quality control labs.
