Analog Devices Inc. LTC2471CDD#TRPBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $10.40 | $10.40 |
| 15+ | $2.39 | $35.85 |
| 25+ | $2.34 | $58.50 |
| 50+ | $2.21 | $110.50 |
| 100+ | $1.95 | $195.00 |
| N+ | $0.39 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 833 |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | I2C |
| Configuration | ADC |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
| Architecture | Sigma-Delta |
| Reference Type | Internal |
| Voltage - Supply, Analog | 2.7V ~ 5.5V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| Features | Selectable Address |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 12-WFDFN Exposed Pad |
| Supplier Device Package | 12-DFN (3x3) |
| ROHS |  |
The LTC2471CDD#TRPBF is a high-performance 16-bit analog-to-digital converter from Analog Devices, designed for precision measurement applications. It features a single input channel and a sampling rate of 833 SPS, ensuring accurate conversion of slow-moving signals. The device integrates an internal reference and communicates via a simple I2C interface, reducing external component requirements. Its compact 12-WFDFN package and wide operating temperature range make it suitable for industrial, medical, and portable instrumentation.
- High Precision: 16-bit resolution provides fine detail for accurate measurement in sensor and instrumentation applications.
- Integrated Reference: The internal reference minimizes external parts, simplifying design and improving system reliability.
- Simple Digital Interface: I2C communication reduces pin count and simplifies connection to microcontrollers and digital systems.
- Compact Package: The 12-WFDFN exposed pad package saves valuable board space in space-constrained designs.
Precision Sensor Digitization
The 16-bit resolution and 833 SPS sampling rate make the LTC2471CDD#TRPBF ideal for accurately digitizing slow-varying signals from precision sensors like thermocouples, RTDs, and strain gauges, ensuring high measurement fidelity.
Industrial Process Control
In industrial automation, this ADC's internal reference simplifies design and reduces external component count, making it suitable for 4-20 mA loop transmitters and process monitors where stable, accurate conversions are critical.
Portable Instrumentation
With its low power consumption and compact 12-WFDFN package, the LTC2471 is well-suited for battery-powered handheld multimeters and data loggers requiring high-resolution measurements in a small footprint.
Data Acquisition Systems
The I2C interface allows for easy integration into multi-sensor data acquisition systems, enabling direct connection to microcontrollers without complex parallel wiring, thus simplifying PCB layout and reducing system cost.
Medical Monitoring Devices
For medical instrumentation such as patient monitors, the high resolution ensures accurate reading of physiological signals, while the 0°C to 70°C temperature range covers standard clinical environments.
- Q: What type of ADC is the LTC2471CDD#TRPBF?
- A: It is a 16-bit analog-to-digital converter (ADC) with an internal reference.
- Q: What is the resolution of this ADC?
- A: The LTC2471CDD#TRPBF offers 16-bit resolution.
- Q: What is the sampling rate?
- A: The sampling rate is 833 SPS (samples per second).
- Q: How many input channels does it have?
- A: It features a single (1) input channel.
- Q: What interface does it use?
- A: It uses the I2C interface for communication.
- Q: What is the package type?
- A: It comes in a 12-WFDFN exposed pad package.
