Analog Devices Inc. LTC3559EUD#PBF
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $7.90 | $7.90 |
| 15+ | $7.65 | $114.75 |
| 25+ | $7.49 | $187.25 |
| 50+ | $7.07 | $353.50 |
| 100+ | $6.24 | $624.00 |
| N+ | $1.25 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc. |
| Product Series | |
| Packaging | Tube | |
| Battery Chemistry | Lithium Ion/Polymer |
| Number of Cells | 1 |
| Current - Charging | Constant - Programmable |
| Programmable Features | - |
| Fault Protection | - |
| Charge Current - Max | 950mA |
| Battery Pack Voltage | 4.2V |
| Voltage - Supply (Max) | 5.5V |
| Interface | USB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-WFQFN Exposed Pad |
| Supplier Device Package | 16-QFN (3x3) |
| ROHS |  |
The LTC3559EUD is a compact battery charger IC from Analog Devices, tailored for single-cell Lithium Ion/Polymer batteries. It provides a maximum charge current of 950mA and maintains a battery voltage of 4.2V. The charger includes a USB interface for easy connectivity. With an operating temperature range of -40°C to 85°C (TA), it is suitable for a variety of portable applications. The device is available in a 16-WFQFN exposed pad package.
- High Integration: USB interface reduces external components for simpler PCB design.
- Space-Saving: 16-WFQFN package is ideal for compact consumer electronics.
- Reliable Charging: Provides a constant 4.2V for single-cell Li-Polymer batteries.
- Versatile Temperature Range: Operates from -40°C to 85°C (TA) for diverse applications.
Wearable Fitness Trackers
The 950mA charge current and USB interface make it perfect for charging single-cell Li-Polymer batteries in fitness bands and smart watches.
Portable Audio Players
Its compact 16-WFQFN package and reliable 4.2V regulation support high-quality audio devices that require clean, stable power.
Bluetooth Headsets
For small, single-cell Li-Polymer batteries in wireless headsets, the LTC3559EUD offers a simple and efficient charging solution.
Digital Cameras
It can be used in compact digital cameras to charge their Li-Ion/Polymer batteries via USB, providing a convenient charging method.
Handheld Gaming Consoles
The wide temperature range and robust design make it suitable for portable gaming devices used in various environments.
- Q: What battery chemistry does the LTC3559EUD support?
- A: It supports Lithium Ion/Polymer batteries.
- Q: How many cells can it charge?
- A: It is designed for a single cell (1).
- Q: What is the maximum charge current?
- A: The maximum charge current is 950mA.
- Q: What is the battery voltage?
- A: The battery voltage is 4.2V.
- Q: Does it have a USB interface?
- A: Yes, it features a USB interface.
- Q: What is the operating temperature range?
- A: It operates from -40°C to 85°C (TA).
