M2S060T-FG484 SmartFusion2 SoC FPGA - High-Performance Programmable Logic with Embedded ARM Processing

The M2S060T-FG484 is a high-performance System-on-Chip (SoC) FPGA from Microchip Technology's SmartFusion®2 family, combining an ARM® Cortex®-M3 microcontroller with 60,000 logic modules in a compact 484-FPBGA package. This versatile programmable logic device integrates 256KB Flash and 64KB RAM, making it ideal for industrial automation, automotive systems, aerospace applications, and secure communications requiring both FPGA fabric and embedded processing in a single chip.

Key Features & Benefits

• Dual Architecture: ARM Cortex-M3 MCU core running at 166MHz plus 60K logic module FPGA fabric for maximum flexibility in embedded system design
• Rich Connectivity: CANbus, Ethernet, I2C, SPI, UART/USART, USB interfaces enable seamless integration with industrial protocols and communication standards
• High-Speed Peripherals: DDR memory controller, PCIe, and SERDES support demanding applications requiring high-bandwidth data processing
• Industrial Grade Reliability: Operating temperature range 0°C to 85°C (TJ) ensures reliable performance in harsh industrial environments
• Compact Package: 484-FPBGA (23x23mm) footprint optimized for space-constrained embedded designs
• Active Status & Long-Term Availability: Full manufacturer support with guaranteed long-term availability for production designs

Target Applications

The M2S060T-FG484 SmartFusion2 SoC FPGA is perfect for:

• Motor Control Systems: Precision control with programmable logic and real-time processing
• Industrial Automation: PLC controllers, factory automation, and process control systems
• Secure Communications: Encrypted data transmission with hardware security features
• Embedded Vision Systems: Image processing and machine vision applications
• Mixed-Signal Processing: Applications requiring both analog and digital signal processing
• Automotive Electronics: Advanced driver assistance systems (ADAS) and vehicle control units

Why Choose SmartFusion2 M2S060T-FG484?

Engineers choose the M2S060T-FG484 when they need the flexibility of programmable logic combined with the deterministic performance of a microcontroller. The integrated ARM Cortex-M3 handles real-time control tasks while the FPGA fabric accelerates parallel processing, custom peripherals, and hardware-based algorithms. This architecture eliminates the need for separate MCU and FPGA chips, reducing board space, power consumption, and system complexity.

Documentation & Support

Full datasheets, reference designs, development tools, and technical support available from Microchip Technology. RoHS compliant with complete traceability documentation for aerospace and automotive qualification requirements.

No datasheet available. Please contact sales@hqickey.com for the latest datasheet.
