Analog Devices Inc./Maxim Integrated MAX1069BEUD+
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $31.57 | $31.57 |
| 15+ | $30.57 | $458.55 |
| 25+ | $29.91 | $747.75 |
| 50+ | $28.25 | $1,412.50 |
| 100+ | $24.92 | $2,492.00 |
| N+ | $4.98 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Factory | Tube |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 58.6k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | I2C |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| Features | Selectable Address |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
| ROHS |  |
The MAX1069BEUD+ is a 14-bit, 58.6k SPS single-channel analog-to-digital converter from Analog Devices. Featuring an I2C interface and S/H-ADC architecture, it delivers high-resolution conversion for precision measurement applications. With flexible reference options and a compact 14-TSSOP package, this ADC is ideal for portable instruments, medical devices, and industrial sensors.
- High Resolution: 14-bit conversion provides exceptional accuracy for demanding measurement applications.
- I2C Interface: Simple two-wire interface reduces pin count and simplifies system integration.
- Flexible Reference: Supports both external and internal references for design flexibility.
- Compact TSSOP Package: Small footprint ideal for space-constrained portable designs.
High-Resolution Sensor Measurement
The 14-bit resolution of the MAX1069BEUD+ enables precise measurement of slow-changing signals like temperature, strain, and chemical sensors, ideal for laboratory and industrial instrumentation.
Portable Medical Devices
With its I2C interface and compact TSSOP package, this ADC is well-suited for portable medical devices such as glucose meters and pulse oximeters, where low power and small size are critical.
Smart Building Automation
In building automation systems, the ADC digitizes signals from environmental sensors (temperature, humidity, CO2) with high accuracy for efficient HVAC control.
Precision Weigh Scales
The high resolution supports accurate weight measurement in industrial and retail scales, converting load cell outputs with minimal error.
Data Acquisition for Research
For scientific data acquisition, the 14-bit resolution and I2C interface allow easy integration with microcontrollers for high-precision experimental measurements.
- Q: What is the resolution of the MAX1069BEUD+?
- A: The MAX1069BEUD+ is a 14-bit analog-to-digital converter.
- Q: What is the sampling rate?
- A: It has a sampling rate of 58.6k SPS.
- Q: How many channels does it have?
- A: This ADC features a single input channel.
- Q: What interface does it use?
- A: It uses an I2C interface for communication.
- Q: What is the architecture?
- A: It uses a S/H-ADC (sample and hold) architecture.
- Q: What is the package type?
- A: It comes in a 14-TSSOP (0.173", 4.40mm Width) package.
