Analog Devices Inc./Maxim Integrated MAX1069CCUD
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $56.08 | $56.08 |
| 15+ | $12.90 | $193.50 |
| 25+ | $12.62 | $315.50 |
| 50+ | $11.92 | $596.00 |
| 100+ | $10.52 | $1,052.00 |
| N+ | $2.10 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 58.6k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | I2C |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 4.75V ~ 5.25V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
| Features | Internal Oscillator |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
The MAX1069CCUD is a 14-bit analog-to-digital converter featuring a S/H-ADC architecture with a single input channel. It achieves a sampling rate of 58.6k SPS, making it suitable for a wide range of precision measurement applications. The I2C interface allows for simple two-wire connection to microcontrollers, reducing pin count. With both external and internal reference options, it offers design flexibility. Operating from -40°C to 85°C, this ADC is packaged in a compact 14-TSSOP, ideal for space-constrained designs.
- I2C Interface: Two-wire interface simplifies PCB design and saves GPIO pins.
- 14-Bit Resolution: Provides high accuracy for precision measurement applications.
- Dual Reference Options: Internal or external reference for design flexibility.
- Compact Package: 14-TSSOP ideal for portable and space-limited devices.
- Wide Temperature Range: -40°C to 85°C suitable for industrial environments.
Portable Medical Devices
The I2C interface and 14-bit resolution make the MAX1069CCUD ideal for compact medical devices like glucose meters and pulse oximeters.
Industrial Sensor Interfaces
Single-channel precision conversion is suitable for industrial pressure transmitters and temperature transducers requiring high accuracy.
Consumer Electronics
The small 14-TSSOP package and I2C interface enable integration into smart home devices, wearables, and audio equipment.
Data Acquisition
With 58.6k SPS sampling rate, this ADC can handle moderate-speed signals in laboratory data acquisition systems.
Battery Monitoring
The internal reference option simplifies design in battery-powered systems where PCB space is limited.
Environmental Sensors
Ideal for air quality monitors and weather stations requiring precise analog-to-digital conversion of sensor outputs.
- Q: What is the MAX1069CCUD?
- A: It is a 14-bit analog-to-digital converter with a S/H-ADC architecture.
- Q: What is the resolution?
- A: It provides 14-bit resolution.
- Q: What is the sampling rate?
- A: The sampling rate is 58.6k SPS.
- Q: How many channels does it have?
- A: It has 1 input channel.
- Q: What interface does it use?
- A: It uses the I2C interface.
- Q: What is the package type?
- A: It comes in a 14-TSSOP package.
