Analog Devices Inc./Maxim Integrated MAX1127EGK
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $262.92 | $262.92 |
| 15+ | $60.47 | $907.05 |
| 25+ | $59.16 | $1,479.00 |
| 50+ | $55.87 | $2,793.50 |
| 100+ | $49.30 | $4,930.00 |
| N+ | $9.86 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 65M |
| Number of Inputs | 4 |
| Input Type | Differential |
| Data Interface | LVDS - Serial |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 4 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 1.7V ~ 1.9V |
| Voltage - Supply, Digital | 1.7V ~ 1.9V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 68-VFQFN Exposed Pad |
| Supplier Device Package | 68-QFN (10x10) |
The MAX1127EGK is a versatile 12-bit analog-to-digital converter (ADC) from Analog Devices/Maxim Integrated, designed for multi-channel high-speed applications. It offers a sampling rate of 65M SPS and features 4 input channels with an LVDS - Serial interface for reduced signal noise and simplified routing. The S/H-ADC architecture ensures accurate sampling, and the external or internal reference options provide design flexibility. Packaged in a compact 68-VFQFN Exposed Pad, this ADC is ideal for medical imaging, communications, and industrial automation.
- Multi-Channel Flexibility: 4 input channels enable simultaneous sampling of multiple signals, reducing system cost and complexity.
- LVDS Serial Interface: Provides high-speed data transfer with low EMI, ideal for noise-sensitive applications.
- Compact Size: The 68-VFQFN package is space-efficient, perfect for portable and densely packed designs.
- Wide Temperature Range: Reliable operation from -40°C to 85°C for automotive and industrial environments.
Multi-Channel Data Acquisition
The 4-channel input and 65M SPS sampling rate make the MAX1127EGK ideal for multi-channel data acquisition systems in industrial monitoring and control.
Medical Imaging and Ultrasound
In ultrasound systems, the multiple channels allow for simultaneous processing of transducer array signals, improving image quality and frame rate.
Communications and Radar
The LVDS serial interface reduces pin count and EMI, making it suitable for high-speed communications and radar systems where signal integrity is critical.
Automotive Sensor Fusion
With its wide temperature range, this ADC is perfect for automotive applications like advanced driver-assistance systems (ADAS) that require multiple sensor inputs.
Portable Test Equipment
The compact 68-VFQFN package and low power consumption make it suitable for battery-powered portable test and measurement devices.
Industrial Automation
For high-speed industrial automation and robotics, the MAX1127EGK provides the necessary speed and multi-channel capability for precise control.
- Q: What is the resolution of the MAX1127EGK?
- A: The MAX1127EGK is a 12-bit analog-to-digital converter (ADC).
- Q: What is the maximum sampling rate?
- A: It supports a sampling rate of 65M SPS (samples per second).
- Q: How many input channels does it have?
- A: This ADC features 4 input channels.
- Q: What digital interface does it use?
- A: It uses an LVDS - Serial digital interface.
- Q: What is the architecture of this ADC?
- A: It utilizes a S/H-ADC (Sample and Hold) architecture.
- Q: What package is the MAX1127EGK available in?
- A: It comes in a 68-VFQFN Exposed Pad package.
