Analog Devices Inc./Maxim Integrated MAX135EWI-T
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $64.48 | $64.48 |
| 15+ | $14.83 | $222.45 |
| 25+ | $14.51 | $362.75 |
| 50+ | $13.70 | $685.00 |
| 100+ | $12.09 | $1,209.00 |
| N+ | $2.42 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 15 |
| Sampling Rate (Per Second) | 16 |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | Parallel |
| Configuration | ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | Multi-Slope |
| Reference Type | External |
| Voltage - Supply, Analog | - |
| Voltage - Supply, Digital | 5V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 28-SOIC |
The MAX135EWI-T from Analog Devices is a 15-bit, single-channel analog-to-digital converter designed for precision measurement applications. It features a parallel interface for easy integration with digital systems. With a sampling rate of 16 SPS, it is optimized for accurate, low-speed data acquisition. Its external reference input allows for flexible scaling of the input range. This ADC is well-suited for industrial and scientific instruments where accuracy is paramount.
- High Resolution (15-bit): Provides fine measurement detail, essential for precision instrumentation and control.
- Simple Parallel Interface: The parallel output simplifies connection to microprocessors and DSPs, reducing software overhead.
- External Reference Support: Allows the user to set the full-scale range, providing flexibility in various applications.
- Wide Operating Temperature: Rated for -40°C to 85°C, it is suitable for a broad range of industrial environments.
High-Precision Weigh Scales
The 15-bit resolution and low sampling rate of 16 SPS are ideal for weigh scale applications where stability and accuracy are more critical than speed.
Industrial Process Transmitters
In industrial settings, this ADC can digitize slow-changing signals from pressure or temperature transmitters, providing reliable data for process monitoring.
Scientific Instrumentation
For laboratory equipment like digital multimeters or precision voltage sources, the MAX135EWI-T offers the necessary resolution for accurate measurements.
Battery-Powered Devices
Its low-speed operation and parallel interface make it suitable for portable instruments where power consumption is a concern.
Data Logging Systems
When combined with a microcontroller, it can be used in data loggers to record environmental or physical parameters over time.
Calibration Equipment
The high resolution and external reference support make it useful in calibration systems that require a precise, known ADC transfer function.
- Q: What is the MAX135EWI-T ADC?
- A: It is a 15-bit, single-channel analog-to-digital converter from Analog Devices/Maxim with a parallel interface.
- Q: What is the resolution of this ADC?
- A: The MAX135EWI-T provides a resolution of 15 bits, offering good precision for various data acquisition needs.
- Q: What is the sampling rate?
- A: It has a sampling rate of 16 SPS, which is suitable for low-speed, high-precision applications like weigh scales.
- Q: How many channels does it have?
- A: This ADC has 1 input channel, making it a single-ended input device.
- Q: What interface does it use?
- A: It features a parallel interface for direct connection to microprocessors and digital systems.
- Q: What is the package type?
- A: It comes in a 28-SOIC (0.295", 7.50mm Width) package, suitable for standard surface-mount assembly.
