Analog Devices Inc./Maxim Integrated MAX1420CCM
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $63.64 | $63.64 |
| 15+ | $14.64 | $219.60 |
| 25+ | $14.32 | $358.00 |
| 50+ | $13.52 | $676.00 |
| 100+ | $11.93 | $1,193.00 |
| N+ | $2.39 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 60M |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 3.135V ~ 3.465V |
| Voltage - Supply, Digital | 2.7V ~ 3.63V |
| Features | Simultaneous Sampling |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 48-LQFP |
| Supplier Device Package | 48-LQFP (7x7) |
The MAX1420CCM is a high-performance 12-bit analog-to-digital converter (ADC) from Analog Devices, designed for demanding applications requiring fast and accurate signal conversion. With a sampling rate of 60 MSPS and a single input channel, this ADC excels in high-speed data acquisition, medical imaging, and communications systems. Its parallel interface ensures efficient data transfer to microcontrollers or DSPs. The device operates within a 0°C to 70°C temperature range and comes in a compact 48-LQFP package, making it suitable for space-constrained industrial and instrumentation designs.
- High-Speed Sampling: 60 MSPS sampling rate enables the capture of fast-changing signals, ideal for high-frequency applications.
- Precise 12-Bit Resolution: Provides 4096 levels of quantization, ensuring accurate representation of analog input signals.
- Flexible Reference Options: Supports both external and internal references, allowing designers to optimize for accuracy or simplicity.
- Parallel Interface: Facilitates high-throughput data transfer to host processors, minimizing latency in real-time systems.
High-Speed Data Acquisition Systems
The MAX1420CCM's 60 MSPS sampling rate and 12-bit resolution make it ideal for digitizing high-frequency signals in data acquisition systems, ensuring accurate capture of fast transient events.
Medical Imaging Equipment
In ultrasound and other medical imaging devices, the high-speed parallel output of this ADC enables real-time processing of sensor data, delivering crisp, high-resolution images for diagnostic purposes.
Communications Infrastructure
For base stations and software-defined radios, the MAX1420CCM digitizes IF (intermediate frequency) signals with high linearity, supporting reliable data transmission and reception.
Industrial Automation and Control
This ADC can be used in industrial control loops where rapid, precise conversion of analog sensor signals (e.g., from encoders or current sensors) is required for real-time feedback and process regulation.
Test and Measurement Instruments
In oscilloscopes and spectrum analyzers, the 12-bit resolution and 60 MSPS sampling rate allow for detailed analysis of waveforms, capturing both amplitude and timing information accurately.
Radar and Lidar Systems
The high sampling rate of the MAX1420CCM is well-suited for digitizing return pulses in radar and lidar systems, enabling precise distance and velocity measurements.
- Q: What type of ADC is the MAX1420CCM?
- A: The MAX1420CCM is a 12-bit, single-channel, sample-and-hold (S/H) analog-to-digital converter with a parallel interface.
- Q: What is the resolution of the MAX1420CCM?
- A: The MAX1420CCM has a resolution of 12 bits, providing 4096 discrete output levels.
- Q: What is the maximum sampling rate of the MAX1420CCM?
- A: The MAX1420CCM supports a maximum sampling rate of 60 MSPS (60M samples per second).
- Q: How many input channels does the MAX1420CCM have?
- A: It has a single input channel (1 channel).
- Q: What interface does the MAX1420CCM use?
- A: It uses a parallel interface for data output.
- Q: What is the operating temperature range?
- A: The MAX1420CCM operates from 0°C to 70°C and is available in a 48-LQFP package.
