Analog Devices Inc./Maxim Integrated MAX17301G+T
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $12.30 | $12.30 |
| 15+ | $2.83 | $42.45 |
| 25+ | $2.77 | $69.25 |
| 50+ | $2.62 | $131.00 |
| 100+ | $2.31 | $231.00 |
| N+ | $0.46 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | ModelGauge™ |
| Packaging | Factory | Tape & Reel (TR) |
| Function | Fuel Gauge |
| Battery Chemistry | Lithium Ion/Polymer |
| Number of Cells | 1 |
| Fault Protection | Over Current, Over Temperature, Over/Under Voltage, Short Circuit |
| Interface | I2C |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 14-WFDFN Exposed Pad |
| Supplier Device Package | 14-TDFN (3x3) |
| ROHS |  |
The MAX17301G+T from Analog Devices is a sophisticated Fuel Gauge IC engineered for single-cell Lithium Ion/Polymer batteries. It integrates comprehensive fault protection including overcurrent, overtemperature, and over/under voltage safeguards. Featuring an I2C interface and a compact 14-WFDFN package, this controller is ideal for portable electronics, medical devices, and industrial handhelds requiring precise battery monitoring and reliable operation across a wide temperature range.
- Accurate State-of-Charge Monitoring: The fuel gauge function provides precise battery data, extending device runtime and improving user experience.
- Comprehensive Safety Protection: Integrated Over Current, Over Temperature, Over/Under Voltage, and Short Circuit protection ensures safe operation under fault conditions.
- Reliable in Extreme Environments: With a -40°C to 85°C operating range, it is suitable for industrial and outdoor applications.
- Space-Saving Design: The compact 14-WFDFN Exposed Pad package is ideal for space-constrained portable devices.
Smartphone Battery Packs
Integrate the MAX17301G+T to provide accurate fuel gauging and robust protection for single-cell Lithium Ion/Polymer batteries in smartphones, ensuring longer runtime and safe operation.
Portable Medical Devices
Use this fuel gauge in single-cell powered medical monitors and diagnostic tools. Its I2C interface allows for precise data logging, while its protection features ensure patient safety.
High-Performance Tablets
Deploy in tablets to manage the single-cell Li-Po battery. The device's over/under voltage and short circuit protection safeguard the device during fast charging and heavy use.
Industrial Handheld Terminals
Employ the MAX17301G+T in rugged handheld scanners and PDAs. Its -40°C to 85°C operating range ensures reliable performance in demanding industrial environments.
Portable Power Banks
Incorporate this fuel gauge into compact power banks. It accurately tracks charge state and provides essential protection against overcurrent and overtemperature events during high-drain recharging.
Wearable Electronics
Utilize this IC in smartwatches and fitness trackers. The small 14-WFDFN package and low power consumption make it ideal for space-constrained, battery-powered wearables.
- Q: What is the primary function of the MAX17301G+T?
- A: It is a Fuel Gauge IC designed for precise battery state monitoring.
- Q: Which battery chemistries are supported?
- A: It supports Lithium Ion/Polymer batteries.
- Q: How many cells can this fuel gauge monitor?
- A: It is designed for single-cell (1) battery packs.
- Q: What fault protection features does it include?
- A: It provides Over Current, Over Temperature, Over/Under Voltage, and Short Circuit protection.
- Q: What communication interface does it use?
- A: It uses the I2C interface for data communication.
- Q: What is the operating temperature range and package type?
- A: It operates from -40°C to 85°C (TA) and comes in a 14-WFDFN Exposed Pad package.
