Analog Devices Inc./Maxim Integrated MAX8559EBAGJ
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $6.80 | $6.80 |
| 15+ | $1.56 | $23.40 |
| 25+ | $1.53 | $38.25 |
| 50+ | $1.45 | $72.50 |
| 100+ | $1.28 | $128.00 |
| N+ | $0.26 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 2 |
| Voltage - Input (Max) | 6.5V |
| Voltage - Output (Min/Fixed) | 3V, 2.85V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.12V @ 100mA |
| Current - Output | 300mA, 300mA |
| Current - Quiescent (Iq) | 290 µA |
| Current - Supply (Max) | - |
| PSRR | 70dB ~ 54dB @ 10kHz ~ 100kHz |
| Control Features | Current Limit, Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-WFBGA, CSPBGA |
| Supplier Device Package | 8-UCSP (2.02x1.02) |
The MAX8559EBAGJ from Analog Devices is a dual-output low dropout linear regulator delivering 3V and 2.85V rails, each rated for 300mA. Its low 0.12V dropout at 100mA and 290µA quiescent current make it ideal for battery-operated devices. With 70dB PSRR at 10kHz, it provides clean, stable power for sensitive analog and RF circuits. The compact 8-UCSP package saves valuable board space in portable and wearable designs.
- Dual Outputs for Design Flexibility: Provides two independent regulated rails (3V and 2.85V) in a single package, reducing component count and simplifying power sequencing.
- Low Dropout for Extended Battery Life: 0.12V dropout at 100mA allows operation close to the battery's end-of-life voltage, maximizing usable capacity.
- High PSRR for Noise-Sensitive Circuits: 70dB rejection at 10kHz filters out switching noise, ensuring clean power for RF and audio applications.
- Compact 8-UCSP Package: The tiny 2.02x1.02mm footprint is ideal for space-constrained portable devices, enabling miniaturized designs.
Dual-Rail Power for Portable Processors
The dual 3V and 2.85V outputs are ideal for powering core and I/O rails of low-power microcontrollers and DSPs, ensuring stable operation with 70dB PSRR at 10kHz.
Battery-Powered Wearables
With a low 290µA quiescent current and 0.12V dropout at 100mA, this LDO maximizes battery life in smartwatches and fitness trackers while maintaining clean power.
RF Transceiver Power Supply
The high PSRR (70dB at 10kHz) reduces noise coupling from switching regulators, making it suitable for powering RF transceivers and improving signal integrity.
Compact Sensor Modules
The 8-UCSP package (2.02x1.02mm) fits into space-constrained IoT sensor nodes, providing two regulated rails for analog and digital sections.
Multi-Channel Audio Codecs
Separate 3V and 2.85V rails isolate analog and digital supplies, minimizing crosstalk and preserving audio fidelity in portable media players.
Industrial Control Interfaces
Stable dual outputs with 300mA per channel power logic and interface circuits in industrial sensors, ensuring reliable operation across temperature ranges.
- Q: What is the output voltage of the MAX8559EBAGJ?
- A: This dual-output LDO provides two regulated outputs: 3V and 2.85V.
- Q: What is the maximum output current?
- A: Each output can deliver up to 300mA, for a combined total of 600mA.
- Q: What is the input voltage range?
- A: The input voltage range is from 3V to 2.85V, designed for dual-rail applications.
- Q: What is the dropout voltage?
- A: The dropout voltage is a low 0.12V at 100mA per channel, ideal for battery-powered devices.
- Q: What is the quiescent current?
- A: The quiescent current is 290µA, helping to extend battery life in portable electronics.
- Q: What package is available?
- A: It comes in a compact 8-UCSP (2.02x1.02) package, saving PCB space.
MAX8559EBAGJ.pdf
- Q: What is the output voltage of the MAX8559EBAGJ?
- A: This dual-output LDO provides two regulated outputs: 3V and 2.85V.
- Q: What is the maximum output current?
- A: Each output can deliver up to 300mA, for a combined total of 600mA.
- Q: What is the input voltage range?
- A: The input voltage range is from 3V to 2.85V, designed for dual-rail applications.
- Q: What is the dropout voltage?
- A: The dropout voltage is a low 0.12V at 100mA per channel, ideal for battery-powered devices.
- Q: What is the quiescent current?
- A: The quiescent current is 290µA, helping to extend battery life in portable electronics.
- Q: What package is available?
- A: It comes in a compact 8-UCSP (2.02x1.02) package, saving PCB space.
