NXP USA Inc. MC9S08AC60CFDE
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $8.11 | $8.11 |
| 15+ | $7.86 | $117.90 |
| 25+ | $7.69 | $192.25 |
| 50+ | $7.26 | $363.00 |
| 100+ | $6.41 | $641.00 |
| N+ | $1.28 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | NXP USA Inc. |
| Product Series | S08 |
| Packaging | Tray | Tray |
| Core Processor | S08 |
| Core Size | 8-Bit |
| Speed | 40MHz |
| Connectivity | I2C, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Number of I/O | 38 |
| Program Memory Size | 60KB (60K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Data Converters | A/D 8x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 48-QFN-EP (7x7) |
| Package / Case | 48-VFQFN Exposed Pad |
| ROHS |  |
The MC9S08AC60CFDE from NXP is an 8-bit microcontroller based on the S08 core, operating at up to 40MHz. It provides 60KB of flash memory and 2KB of RAM, with a supply voltage range of 2.7V to 5.5V. Housed in a 48-VFQFN package, it includes LVD, POR, PWM, and watchdog timers. Designed for -40°C to 85°C environments, it is a cost-effective choice for automotive body electronics, industrial control, and consumer appliances.
- Wide supply voltage: 2.7V-5.5V allows use in both 3.3V and 5V systems without level shifting.
- Large flash memory: 60KB provides ample space for complex firmware in 8-bit applications.
- High-speed 8-bit core: 40MHz execution delivers responsive real-time control.
- Compact package: 48-VFQFN with exposed pad minimizes board space and aids thermal dissipation.
Automotive Body Electronics
5V operation and 40MHz speed support window lift, mirror control, and lighting modules in vehicles.
Industrial Automation
With 60KB flash and PWM, it handles sensor interfacing and actuator control in PLC I/O modules.
White Goods
Its wide voltage range and robust WDT make it reliable for washing machine and refrigerator control boards.
HVAC Systems
PWM outputs and 5V compatibility drive fan motors and damper actuators in commercial HVAC controllers.
Security and Access Control
Low-cost 8-bit solution for keypads, card readers, and door lock controllers with -40°C to 85°C operation.
Power Tools
Compact VFQFN package and 5V logic enable integration into cordless drill and saw control electronics.
- Q: What is the core processor?
- A: It uses the S08 core, an 8-bit architecture from NXP, running at up to 40MHz.
- Q: What is the supply voltage range?
- A: It operates from 2.7V to 5.5V, providing flexibility for both 3.3V and 5V systems.
- Q: How much flash memory is available?
- A: It has 60KB of flash program memory and 2KB of RAM.
- Q: What is the operating temperature range?
- A: It is rated for -40°C to 85°C, suitable for most industrial and consumer applications.
- Q: What package is it available in?
- A: It comes in a 48-pin VFQFN package with exposed pad for thermal management.
