Microchip Technology MCP1825-5002E/AT
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $4.76 | $4.76 |
| 15+ | $1.09 | $16.35 |
| 25+ | $1.07 | $26.75 |
| 50+ | $1.01 | $50.50 |
| 100+ | $0.89 | $89.00 |
| N+ | $0.18 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | |
| Packaging | Tube | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.35V @ 500mA |
| Current - Output | 500mA |
| Current - Quiescent (Iq) | 220 μA |
| Current - Supply (Max) | - |
| PSRR | 60dB (100Hz) |
| Control Features | Enable, Power Good |
| Protection Features | Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-5 |
| Supplier Device Package | TO-220-5 |
| ROHS |  |
The MCP1825-5002E/AT is a fixed 5.0V LDO regulator from Microchip Technology, capable of delivering 500mA. With a low dropout of 0.35V at full load and a quiescent current of 220μA, it balances efficiency and performance. The TO-220-5 package ensures excellent thermal management, while 60dB PSRR at 100Hz provides clean power for industrial and audio applications.
- High Current Capacity: 500mA output supports a wide range of digital and analog loads.
- Excellent Thermal Performance: TO-220-5 package dissipates heat efficiently, ensuring reliability under continuous load.
- Low Dropout: 0.35V at 500mA minimizes power loss and allows operation from a 5.35V input.
- Good Ripple Rejection: 60dB at 100Hz filters mains-frequency noise, ideal for audio and precision circuits.
5V Digital Logic Power
Provides a stable 5V rail at 500mA for microcontrollers, FPGAs, and digital logic circuits, with 0.35V dropout ensuring regulation even with a 5.5V input.
Industrial Control Systems
The TO-220-5 package dissipates heat effectively, making it suitable for industrial actuators and PLCs that require continuous 500mA loads.
Automotive Sensor Modules
With 60dB PSRR at 100Hz, it filters alternator ripple, providing clean 5V power to engine sensors and telematics units.
Bench Power Supply Output Stage
As a post-regulator, it delivers a precise 5V output with low noise for laboratory test equipment.
Audio Equipment Power
The low-noise characteristics and 500mA capability make it ideal for powering analog audio circuits like preamplifiers and mixers.
Networking Equipment
Provides reliable 5V power for routers, switches, and small networking devices, with thermal robustness for 24/7 operation.
- Q: What is the output voltage of the MCP1825-5002E/AT?
- A: This LDO provides a fixed output voltage of 5.0V.
- Q: What is the maximum output current?
- A: It can deliver up to 500mA of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is from 5.0V up to the maximum rated input, suitable for 5V rail regulation.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.35V at 500mA, allowing efficient regulation with a modest input-to-output headroom.
- Q: What is the quiescent current?
- A: The quiescent current is 220 μA, balancing performance with power efficiency.
- Q: What package is the MCP1825-5002E/AT available in?
- A: It is available in a TO-220-5 package, which offers excellent thermal dissipation for higher current applications.
