Microchip Technology MCP1826S-5002E/AB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.25 | $1.25 |
| 15+ | $1.21 | $18.15 |
| 25+ | $1.19 | $29.75 |
| 50+ | $1.12 | $56.00 |
| 100+ | $0.99 | $99.00 |
| N+ | $0.20 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | |
| Packaging | Tube | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.4V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 220 µA |
| Current - Supply (Max) | - |
| PSRR | 60dB (100Hz) |
| Control Features | - |
| Protection Features | Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220-3 |
| ROHS |  |
The MCP1826S-5002E/AB from Microchip Technology is a fixed 5V low dropout linear regulator capable of delivering 1A of output current. With a low dropout voltage of 0.4V at full load and a quiescent current of 220µA, it offers an excellent balance of performance and efficiency. The TO-220-3 package ensures robust thermal management, while 60dB PSRR at 100Hz provides clean, stable power for a wide range of digital and analog applications.
- Standard 5V Output: Compatible with a wide range of legacy and modern ICs.
- High Current: 1A output supports multiple peripherals.
- Low Dropout: 0.4V at 1A allows operation from 5.4V inputs.
- Low Quiescent Current: 220µA helps maximize battery life.
- Excellent PSRR: 60dB at 100Hz reduces supply noise.
5V Logic and Peripheral Power
The fixed 5V output is ideal for powering legacy logic ICs, sensors, and peripheral interfaces that require a stable 5V rail with up to 1A current.
Arduino and Maker Projects
Provides clean 5V power for microcontrollers, motor drivers, and displays, with low dropout ensuring stable operation from 6V batteries.
Industrial Automation
Powers 5V PLC I/O modules, field transmitters, and control relays, benefiting from 60dB PSRR to reject industrial noise.
Automotive Infotainment
Supplies 5V for USB ports, audio codecs, and display panels in car head units, with TO-220 package handling thermal loads.
Test Equipment
Provides a low-noise 5V reference for benchtop multimeters, oscilloscopes, and signal generators, ensuring measurement accuracy.
Battery-Powered Devices
With 220µA quiescent current, it extends battery life in portable instruments, remote controls, and wireless sensors.
- Q: What is the output voltage of the MCP1826S-5002E/AB?
- A: The fixed output voltage is 5V.
- Q: What is the maximum output current?
- A: It can deliver up to 1A of continuous current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; refer to the datasheet for full specifications.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.4V at 1A load.
- Q: What is the quiescent current?
- A: The quiescent current is 220 µA.
- Q: What package is available?
- A: It comes in a TO-220-3 package.
