Micrel Inc. MIC5305-3.3YD5TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Micrel Inc. |
| Product Series | |
| Packaging | | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.11V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 150 μA |
| Current - Supply (Max) | - |
| PSRR | 85dB ~ 65dB (1kHz ~ 10kHz) |
| Control Features | Current Limit, Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Supplier Device Package | TSOT-23-5 |
The Micrel MIC5305-3.3YD5TR is a high-performance, fixed 3.3V low dropout linear regulator designed for portable and noise-sensitive electronics. It delivers up to 150mA with an exceptionally low dropout voltage of 0.11V, enabling efficient operation from low-voltage supplies. With a low quiescent current of 150μA and excellent PSRR of up to 85dB, it provides clean, stable power for RF, audio, and precision analog circuits while extending battery life.
- Ultra-Low Dropout: 0.11V at 150mA allows operation from very low input voltages, reducing power loss and heat.
- Excellent PSRR: 85dB to 65dB (1kHz-10kHz) ensures superior rejection of power supply noise, critical for RF and audio.
- Low Quiescent Current: 150μA quiescent current significantly extends battery life in portable devices.
- Compact Package: TSOT-23-5 package saves board space, ideal for miniaturized designs.
Portable Battery Devices
The MIC5305-3.3YD5TR's ultra-low dropout of 0.11V and low quiescent current of 150μA make it perfect for powering 3.3V logic from a single Li-Ion cell, maximizing battery runtime.
Wireless Modules and IoT
With high PSRR (85dB at 1kHz), this LDO provides a clean 3.3V supply for RF transceivers, Wi-Fi modules, and Bluetooth SoCs, reducing interference and improving signal quality.
Portable Medical Devices
Its low noise and stable output make it suitable for powering sensors and analog front-ends in glucose meters, pulse oximeters, and other battery-operated medical monitors.
Wearable Electronics
The small TSOT-23-5 package and low power consumption are ideal for space-constrained wearables like smartwatches and fitness trackers, where efficiency and size are critical.
Audio and Multimedia
The high PSRR across a wide frequency range (85dB to 65dB from 1kHz to 10kHz) ensures minimal noise coupling into audio codecs and amplifiers, delivering high-fidelity sound.
Reference Voltage Source
Use this LDO to generate a stable 3.3V reference for ADCs, DACs, and precision op-amps, ensuring accurate and repeatable measurements in instrumentation.
- Q: What is the output voltage of the MIC5305-3.3YD5TR?
- A: It provides a fixed 3.3V output voltage.
- Q: What is the maximum output current?
- A: The maximum output current is 150mA.
- Q: What is the input voltage range?
- A: The input voltage range is not explicitly specified in the provided data; please refer to the datasheet for the full operating range.
- Q: What is the dropout voltage?
- A: The dropout voltage is very low at 0.11V at 150mA, making it ideal for low headroom applications.
- Q: What is the quiescent current?
- A: The quiescent current is only 150 μA, which is excellent for battery-powered devices.
- Q: What package is available?
- A: It comes in a compact TSOT-23-5 package.
