Microchip Technology MIC5315-F4CYMT-TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | |
| Packaging | | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1V/1.2V, 1.5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.2V @ 300mA, 0.2V @ 300mA |
| Current - Output | 300mA, 300mA |
| Current - Quiescent (Iq) | 12 μA |
| Current - Supply (Max) | - |
| PSRR | 65dB ~ 40dB (1kHz ~ 20kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 10-UFDFN, 10-TMLF? |
| Supplier Device Package | 10-TMLF? (2x2) |
| ROHS |  |
The Microchip MIC5315 is a dual-output, 300mA per channel low dropout linear regulator with fixed voltages of 1.0V and 1.2V. Its low 0.2V dropout at full load and 12 μA quiescent current make it highly efficient for battery-powered devices. The 10-TMLF package offers a compact solution for space-constrained designs requiring multiple voltage rails.
- Dual Outputs: Two independent 300mA rails in one package reduce component count and PCB area.
- Low Dropout: 0.2V at 300mA maximizes efficiency and extends battery life.
- Wideband PSRR: 65dB to 40dB from 1kHz to 20kHz ensures clean power for audio and RF circuits.
- Compact Package: 2x2mm TMLF package ideal for portable and wearable devices.
Dual-Rail Microcontrollers
Provides separate 1.0V and 1.2V rails for MCUs and DSPs requiring multiple supply voltages, with 300mA per channel.
Smartphones and Tablets
The compact 2x2mm package and dual outputs are ideal for powering application processors and memory in mobile devices.
FPGA Core and I/O Supplies
Deliver clean power to FPGA core logic and I/O banks with low dropout and good PSRR across a wide frequency range.
Portable Audio Players
With 65dB to 40dB PSRR from 1kHz to 20kHz, it minimizes audio noise in high-fidelity portable players.
Wireless Modules
Stable dual outputs for RF transceivers and baseband processors in IoT modules, ensuring reliable wireless performance.
Battery-Powered Peripherals
12 μA quiescent current helps preserve battery life in wireless mice, keyboards, and other peripherals.
