Microchip Technology MIC5316-F4CYMT-TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $2.00 | $2.00 |
| 15+ | $0.46 | $6.90 |
| 25+ | $0.45 | $11.25 |
| 50+ | $0.43 | $21.50 |
| 100+ | $0.38 | $38.00 |
| N+ | $0.08 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | |
| Packaging | Tape & Reel (TR) | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1V, 1.5V |
| Voltage - Output (Max) | 1.2V |
| Voltage Dropout (Max) | 0.2V @ 300mA, 0.2V @ 300mA |
| Current - Output | 300mA, 300mA |
| Current - Quiescent (Iq) | 12 μA |
| Current - Supply (Max) | - |
| PSRR | 65dB ~ 40dB (1kHz ~ 20kHz) |
| Control Features | Enable, Power On Reset |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 12-UFDFN Exposed Pad, 12-TMLF? |
| Supplier Device Package | 12-TMLF? (2.5x2.5) |
| ROHS |  |
The MIC5316 from Microchip Technology is a dual-output, fixed 1.2V linear regulator delivering up to 300mA per channel. With an ultra-low 12 μA quiescent current and 0.2V dropout at full load, it is engineered for battery-powered and portable applications. The 12-TMLF package offers a compact solution for space-constrained designs.
