Microchip Technology MIC5322-MGYMT-TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $3.90 | $3.90 |
| 15+ | $0.90 | $13.50 |
| 25+ | $0.88 | $22.00 |
| 50+ | $0.83 | $41.50 |
| 100+ | $0.74 | $74.00 |
| N+ | $0.15 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | |
| Packaging | Tape & Reel (TR) | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1.8V, 2.8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.1V @ 150mA, 0.1V @ 150mA |
| Current - Output | 150mA, 150mA |
| Current - Quiescent (Iq) | 190 μA |
| Current - Supply (Max) | - |
| PSRR | 75dB ~ 45dB (1kHz ~ 20kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 6-UFDFN Exposed Pad, 6-TMLF? |
| Supplier Device Package | 6-TMLF? (1.6x1.6) |
| ROHS |  |
The Microchip MIC5322 dual LDO delivers fixed 1.8V and 2.8V outputs, each rated at 150mA. Its 190 µA quiescent current and 0.1V dropout voltage make it ideal for battery-powered applications. With 75dB PSRR at 1kHz, it provides clean, stable power. The 6-TMLF (1.6x1.6) package is perfect for space-constrained designs.
- Versatile Dual Outputs: 1.8V and 2.8V rails suit mixed-voltage systems.
- Low Quiescent Current: 190 µA extends battery life in portable devices.
- High PSRR: 75dB at 1kHz ensures noise-free power for analog circuits.
- Compact Package: 1.6x1.6mm TMLF saves valuable PCB space.
MCU and Peripheral Power
The 1.8V rail powers low-voltage MCUs, while 2.8V supplies sensors and communication interfaces, with low dropout ensuring stable operation.
Portable Health Monitors
Low quiescent current (190 µA) extends battery life in wearable ECG and heart-rate monitors.
Wireless Modules
Clean 2.8V for RF transceivers and 1.8V for baseband logic, with 75dB PSRR reducing interference.
Smart Cards and Readers
Dual outputs power the card interface (1.8V) and reader logic (2.8V), with compact package fitting slim devices.
Industrial IoT Sensors
Stable dual-rail regulation from a 2.8V supply, with high PSRR filtering industrial noise.
Portable Instrumentation
1.8V for digital logic and 2.8V for analog front-ends, with low dropout maintaining accuracy.
- Q: What are the output voltages?
- A: Fixed outputs of 1.8V and 2.8V.
- Q: What is the maximum current?
- A: 150mA per channel.
- Q: What is the input voltage range?
- A: 1.8V to 2.8V.
- Q: What is the dropout voltage?
- A: 0.1V at 150mA.
- Q: What is the quiescent current?
- A: 190 µA.
- Q: What package is available?
- A: 6-TMLF (1.6x1.6).
