Monolithic Power Systems Inc. MP163CGSE-5-Z
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.65 | $0.65 |
| 15+ | $0.63 | $9.45 |
| 25+ | $0.61 | $15.25 |
| 50+ | $0.58 | $29.00 |
| 100+ | $0.51 | $51.00 |
| N+ | $0.10 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Monolithic Power Systems Inc. |
| Product Series | |
| Packaging | Tape & Reel (TR) | |
| Output Isolation | Non-Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Topology | Boost, Buck, Buck-Boost, Flyback |
| Voltage - Start Up | 5.3 V |
| Voltage - Supply (Vcc/Vdd) | 5.4V ~ 6V |
| Duty Cycle | - |
| Frequency - Switching | 28kHz |
| Power (Watts) | 4 W |
| Fault Protection | Current Limiting, Over Load, Short Circuit |
| Control Features | EN, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| ROHS |  |
The MP163CGSE-5-Z from Monolithic Power Systems is a non-isolated offline switcher with an integrated 700V switch and up to 4 W output power. It supports Boost, Buck, Buck-Boost, and Flyback topologies at 28kHz, with a 5.3V start-up threshold and 5.4V to 6V Vcc supply. Current limiting, over-load, and short-circuit protection plus enable and soft-start control make it a compact solution for low-power offline designs in a 16-SOIC package.
- Integrated 700V switch reduces external components in low-power offline designs.
- Multi-topology support (Boost, Buck, Buck-Boost, Flyback) for design flexibility.
- Current limiting, over-load, and short-circuit protection improve reliability.
- Enable and soft-start control support controlled power-up.
- Wide -40°C to 125°C junction temperature range for demanding applications.
Low-Power Offline Bias Supplies
The MP163CGSE-5-Z delivers up to 4 W using an integrated 700V switch, making it suitable for non-isolated bias supplies in offline systems. A 28kHz switching frequency and 5.3V start-up threshold reduce external component requirements.
Buck and Buck-Boost Auxiliary Rails
Supporting Buck and Buck-Boost topologies, the device generates regulated auxiliary rails from a rectified AC bus. The 5.4V to 6V Vcc supply and integrated soft start support stable startup.
Non-Isolated Flyback Power Stages
In Flyback configurations, the MP163CGSE-5-Z provides a compact auxiliary power solution, protected by current limiting, over-load, and short-circuit protection.
Industrial and Appliance Designs
With a -40°C to 125°C junction temperature range and 16-SOIC package, the device suits industrial control, appliance, and metering electronics requiring dependable offline power.
- Q: What topologies does the MP163CGSE-5-Z support?
- A: It supports Boost, Buck, Buck-Boost, and Flyback topologies in a non-isolated configuration.
- Q: What is the maximum output power?
- A: The device delivers up to 4 W.
- Q: Is the power switch integrated?
- A: Yes, it has an internal switch with a 700V breakdown rating.
- Q: What is the Vcc supply range?
- A: The Vcc supply range is 5.4V to 6V, with a 5.3V start-up threshold.
- Q: What protections are included?
- A: Current limiting, over-load, and short-circuit protection.
