Renesas Electronics Corporation MPC9230EI
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Renesas Electronics Corporation |
| Product Series | |
| Packaging | | |
| Type | Clock/Frequency Synthesizer |
| PLL | Yes with Bypass |
| Input | LVCMOS, Crystal |
| Output | LVPECL |
| Number of Circuits | 1 |
| Ratio - Input:Output | 2:1 |
| Differential - Input:Output | No/Yes |
| Frequency - Max | 750MHz |
| Divider/Multiplier | Yes/No |
| Voltage - Supply | 3.135V ~ 3.465V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 28-LCC (J-Lead) |
| Supplier Device Package | 28-PLCC (11.51x11.51) |
| ROHS |  |
The Renesas MPC9230EI is a high-performance Clock/Frequency Synthesizer designed for demanding timing applications. It integrates a PLL with bypass capability, accepting LVCMOS or crystal inputs to generate low-jitter LVPECL outputs up to 750MHz. With a single circuit, it provides a compact solution for systems requiring precise clock generation. Its wide temperature range and 28-LCC package make it suitable for industrial and telecom environments.
- High-Frequency Precision: Generates LVPECL clocks up to 750MHz, meeting the needs of high-speed digital systems.
- Flexible PLL Bypass: The 'Yes with Bypass' PLL allows direct clocking when synthesis is not required, offering design flexibility.
- Wide Temperature Range: Operates from -40°C to 85°C, ensuring reliability in harsh industrial conditions.
- Versatile Input Options: Accepts both LVCMOS and crystal references, simplifying board design.
Telecom Clock Generation
The MPC9230EI's high-frequency LVPECL outputs and PLL with bypass make it ideal for generating precise clocks in telecom infrastructure, ensuring reliable data transmission.
Networking Timing
With support for crystal or LVCMOS references, this synthesizer can generate low-jitter clocks for networking switches and routers, maintaining synchronization across high-speed interfaces.
Processor Clock Generation
Its 750MHz capability and single-circuit design are well-suited for providing the main clock to high-performance processors and FPGAs, reducing component count.
Broadcast Video Synchronization
The LVPECL outputs deliver the clean, high-frequency signals required for professional video equipment, ensuring frame-accurate synchronization in broadcast environments.
Industrial Timing Systems
Rated for -40°C to 85°C, the MPC9230EI operates reliably in industrial settings, generating stable clocks for automation and control systems.
Test and Measurement Equipment
The PLL bypass feature allows engineers to use the device as a flexible frequency source in test equipment, switching between synthesized and direct clock modes.
- Q: What type of device is the MPC9230EI?
- A: The MPC9230EI is a Clock/Frequency Synthesizer from Renesas Electronics Corporation.
- Q: Does the MPC9230EI support PLL?
- A: Yes, it features a PLL with bypass capability, allowing the PLL to be bypassed when direct clocking is needed.
- Q: What are the input and output types?
- A: It accepts LVCMOS or Crystal inputs and provides LVPECL outputs.
- Q: How many circuits does it have and what is the maximum frequency?
- A: It has 1 circuit and supports a maximum frequency of 750MHz.
- Q: What is the operating temperature range?
- A: The operating temperature range is -40°C to 85°C.
- Q: What package is the MPC9230EI available in?
- A: It comes in a 28-LCC (J-Lead) package.
