Monolithic Power Systems Inc. MPQ2013AGG-P
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $2.62 | $2.62 |
| 15+ | $2.54 | $38.10 |
| 25+ | $2.48 | $62.00 |
| 50+ | $2.35 | $117.50 |
| 100+ | $2.07 | $207.00 |
| N+ | $0.41 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Monolithic Power Systems Inc. |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 1.215V |
| Voltage - Output (Max) | 15V |
| Voltage Dropout (Max) | 1.1V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | - |
| Current - Supply (Max) | - |
| PSRR | 58dB ~ 41dB (100Hz ~ 1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 6-VDFN Exposed Pad |
| Supplier Device Package | 6-QFN (2x2) |
| ROHS |  |
The MPQ2013AGG-P from Monolithic Power Systems is a fixed 15V linear regulator designed for space-constrained applications. It delivers up to 150mA of output current with a low 1.1V dropout voltage at full load. Its high PSRR of up to 58dB effectively filters input noise, making it ideal for sensitive analog and mixed-signal circuits. Housed in a compact 6-QFN package, this LDO offers a simple, reliable power solution.
- Stable 15V Output: Provides a precise, fixed 15V rail, simplifying design and ensuring consistent performance for downstream components.
- Excellent Noise Rejection: With 58dB PSRR at 100Hz, it effectively filters ripple and noise, critical for high-precision analog applications.
- Compact Footprint: The 6-QFN (2x2mm) package minimizes board space, ideal for dense, portable designs.
- Low Dropout: The 1.1V dropout at 150mA allows operation with a smaller input-to-output voltage headroom, improving efficiency in battery-powered systems.
Industrial Sensor Power
Power precision analog sensors requiring a stable 15V rail. The MPQ2013AGG-P's low dropout and good PSRR (58dB @ 100Hz) minimize supply-induced noise, ensuring accurate sensor readings in noisy industrial environments.
Battery-Powered Instrumentation
Its low quiescent current and 150mA capability make it suitable for portable instruments. The 1.1V dropout at full load allows efficient use of battery voltage down to 16.1V for a 15V output.
Automotive ECU Sub-Regulation
Generate a clean 15V supply for automotive microcontrollers or interface circuits from a higher, unregulated bus voltage. The small 6-QFN package saves valuable PCB space in space-constrained ECU designs.
Audio Equipment Biasing
Provide a low-noise bias supply for audio op-amps or codecs. The PSRR performance helps reject power supply hum and ripple, contributing to a cleaner audio signal path.
Telecom Line Drivers
Supply a stable voltage for line driver ICs in telecom equipment. The 150mA current capability is sufficient for many driver stages, and the fixed 15V output simplifies power supply design.
- Q: What is the output voltage of the MPQ2013AGG-P?
- A: The MPQ2013AGG-P provides a fixed 15V output.
- Q: What is the maximum output current?
- A: It can deliver up to 150mA of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is from 1.215V up to the maximum rated input (typically 40V, refer to datasheet).
- Q: What is the dropout voltage?
- A: The dropout voltage is typically 1.1V at a 150mA load.
- Q: What is the package type?
- A: It comes in a compact 6-QFN (2x2mm) package.
- Q: Does it offer good noise rejection?
- A: Yes, it features a PSRR of 58dB to 41dB from 100Hz to 1kHz.
