Monolithic Power Systems Inc. MPQ2013GQ-P
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $4.25 | $4.25 |
| 15+ | $0.98 | $14.70 |
| 25+ | $0.95 | $23.75 |
| 50+ | $0.90 | $45.00 |
| 100+ | $0.80 | $80.00 |
| N+ | $0.16 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Monolithic Power Systems Inc. |
| Product Series | |
| Packaging | Factory | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Adjustable |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Min/Fixed) | 1.215V |
| Voltage - Output (Max) | 15V |
| Voltage Dropout (Max) | 0.9V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 9 μA |
| Current - Supply (Max) | 50 μA |
| PSRR | 58dB ~ 41dB (100Hz ~ 1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-VDFN Exposed Pad |
| Supplier Device Package | 8-QFN (3x3) |
| ROHS |  |
The Monolithic Power Systems MPQ2013GQ-P is an adjustable low-dropout linear regulator capable of delivering 150mA with an input voltage up to 15V. It features an ultra-low 9 μA quiescent current and a dropout voltage of 0.9V at full load. The 8-QFN (3x3) package is compact, and the PSRR of 58dB to 41dB (100Hz to 1kHz) ensures good noise rejection for sensitive applications.
- Wide Input Range: Supports up to 15V input, allowing direct connection to higher voltage rails.
- Ultra-Low Quiescent Current: 9 μA extends battery life in always-on applications.
- Adjustable Output: Flexible output voltage setting via external resistors, down to 1.215V reference.
- Compact QFN Package: 3x3mm footprint ideal for miniaturized designs.
Battery-Powered Industrial Monitors
The 9 μA quiescent current and 15V input capability make it ideal for industrial battery monitors that need to operate for years on a single battery.
Automotive Infotainment
With a wide input range up to 15V, this LDO can regulate directly from a car battery, providing a stable 3.3V or 5V rail for infotainment processors.
Portable Test Equipment
The adjustable output and low dropout voltage allow efficient regulation from a 12V battery down to lower voltages for test probes and handheld meters.
Energy Harvesting Systems
In energy harvesting applications, the low quiescent current preserves harvested energy, while the adjustable output matches the load requirements.
Smart Grid Sensors
For grid monitoring sensors, the MPQ2013GQ-P provides a reliable low-power supply from a 12V bus, with PSRR of 58dB at 100Hz to reject line noise.
Medical Implants
The small 3x3 QFN package and low power consumption make it suitable for implantable devices that require a precise, adjustable output voltage.
- Q: What is the output voltage of the MPQ2013GQ-P?
- A: The output voltage is adjustable, with a reference voltage of 1.215V.
- Q: What is the maximum output current?
- A: The maximum output current is 150mA.
- Q: What is the input voltage range?
- A: The input voltage can be up to 15V.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.9V at 150mA output current.
- Q: What is the quiescent current?
- A: The quiescent current is 9 μA.
- Q: What package is available?
- A: The device is available in an 8-QFN (3x3) package.
