Analog Devices Inc./Maxim Integrated MX7576AQ
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $40.84 | $40.84 |
| 15+ | $9.39 | $140.85 |
| 25+ | $9.19 | $229.75 |
| 50+ | $8.68 | $434.00 |
| 100+ | $7.66 | $766.00 |
| N+ | $1.53 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Product Series | |
| Packaging | Bulk | |
| Number of Bits | 8 |
| Sampling Rate (Per Second) | 200k |
| Number of Inputs | 1 |
| Input Type | Single Ended |
| Data Interface | Parallel |
| Configuration | ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 4.75V ~ 5.25V |
| Voltage - Supply, Digital | 4.75V ~ 5.25V |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Grade | - |
| Qualification | - |
| Package / Case | 18-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 18-CDIP |
The MX7576AQ from Analog Devices Inc./Maxim Integrated is an 8-bit analog-to-digital converter with a parallel interface. It achieves a sampling rate of 200k SPS, making it suitable for high-speed data acquisition. This single-channel ADC requires an external reference and is designed for operation over the full military temperature range. Its 18-CDIP package ensures durability in harsh environments. This device is well-suited for military, industrial, and test applications requiring reliable and fast conversion.
- Extended Temperature Range: Operates from -55°C to 125°C, suitable for extreme environments.
- High-Speed Conversion: 200k SPS sampling rate enables real-time digitization of fast-changing signals.
- Rugged Package: Ceramic DIP package provides excellent mechanical and thermal stability.
- Simple Parallel Output: Easy to interface with microprocessors and DSPs without complex serial protocols.
- Proven Reliability: Designed for military-grade applications, ensuring long-term performance.
Military Electronics
The wide -55°C to 125°C temperature range and hermetically sealed CDIP package make this ADC ideal for military avionics and field equipment requiring high reliability.
High-Speed Control Systems
With a 200k SPS sampling rate and parallel output, the MX7576AQ can be used in motor control or power conversion systems where fast, 8-bit digitization is needed.
Industrial Automation
This ADC can digitize sensor signals in factory automation equipment, providing a simple parallel interface to PLCs or industrial microcontrollers.
Test Instrumentation
Its speed and 8-bit resolution make it suitable for embedded test equipment where waveform analysis or signal monitoring is performed.
Space Systems
The robust temperature rating and ceramic package support use in satellite telemetry and other space-constrained applications.
- Q: What is the resolution of the MX7576AQ?
- A: The MX7576AQ is an 8-bit analog-to-digital converter.
- Q: What is the maximum sampling rate?
- A: It supports a sampling rate of 200k SPS.
- Q: How many channels does this ADC have?
- A: It has a single (1) input channel.
- Q: What interface does it use?
- A: It features a parallel interface for data transfer.
- Q: What is the operating temperature range?
- A: It operates over the military temperature range of -55°C to 125°C.
- Q: What package is the MX7576AQ available in?
- A: It is offered in an 18-CDIP (0.300", 7.62mm) package.
