onsemi NCP1562BDBR2G
Regular price
$1.19
Regular price
$1.25
Sale price
$1.19
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.19 | $1.19 |
| 15+ | $1.15 | $17.25 |
| 25+ | $1.13 | $28.25 |
| 50+ | $1.06 | $53.00 |
| 100+ | $0.94 | $94.00 |
| N+ | $0.19 | Price Inquiry |
Shipping calculated at checkout.
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | onsemi |
| Product Series | |
| Packaging | Marketplace | Bulk |
| Output Type | Transistor Driver |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive, Isolation Capable |
| Topology | Forward Converter |
| Number of Outputs | 2 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 23.2V ~ 100V |
| Frequency - Switching | 246kHz ~ 1MHz |
| Duty Cycle (Max) | 85% |
| Synchronous Rectifier | Yes |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Current Limit, Frequency Control, Ramp, Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
| ROHS |  |
NCP1562BDBR2G.pdf
×
