Nexperia USA Inc. NEX80801DAZ
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | Dhs. 0.97 | Dhs. 0.97 |
| 15+ | Dhs. 0.93 | Dhs. 13.95 |
| 25+ | Dhs. 0.91 | Dhs. 22.75 |
| 50+ | Dhs. 0.86 | Dhs. 43.00 |
| 100+ | Dhs. 0.76 | Dhs. 76.00 |
| N+ | Dhs. 0.15 | Price Inquiry |
Request Quote / Inquiry
NEX80801DAZ - High-Performance Isolated Flyback Controller IC
The NEX80801DAZ from Nexperia is a precision-engineered flyback controller IC designed for secondary side synchronous rectification (SR) in isolated power supply applications up to 65W. This advanced controller delivers exceptional efficiency and reliability for industrial, telecom, and automotive power conversion systems.
Key Features & Benefits
- High Efficiency Design: Secondary side synchronous rectification topology maximizes power conversion efficiency
- Wide Input Range: 10V to 83V supply voltage accommodates diverse power architectures
- Comprehensive Protection: Integrated current limiting, over-load, over-power, over-temperature, over-voltage, and short circuit protection
- Optimized Switching: 65kHz switching frequency with 78% duty cycle for balanced performance
- Soft Start Control: Reduces inrush current and stress on components during power-up
- Extended Temperature Range: -40°C to 125°C junction temperature for harsh environments
- Compact Surface Mount: Space-saving TSSOP-6 package for high-density PCB layouts
Applications
- Industrial power supplies and converters
- Telecom and networking equipment
- Automotive electronics and battery management
- Medical device power systems
- LED driver circuits
Quality & Compliance
This component is RoHS compliant, meeting international environmental standards for hazardous substance restrictions. All units are sourced through authorized distribution channels with full traceability and come with manufacturer documentation including datasheets and compliance certificates.
Design Support
Complete technical documentation, reference designs, and application notes are available to accelerate your design-in process. Our engineering team provides expert support for circuit optimization, component selection, and troubleshooting.
Packaging: Available in Tape & Reel for automated assembly processes, ensuring reliable handling and placement in high-volume manufacturing environments.
| Product attributes | Property Value |
| Manufacturer | Nexperia USA Inc. |
| Product Series | NEX8080 |
| Packaging | Tape & Reel (TR) | |
| Output Isolation | Isolated |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Topology | Flyback, Secondary Side SR |
| Voltage - Start Up | 17 V |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 83V |
| Duty Cycle | 78% |
| Frequency - Switching | 65kHz |
| Power (Watts) | 65 W |
| Fault Protection | Current Limiting, Over Load, Over Power, Over Temperature, Over Voltage, Short Circuit |
| Control Features | Soft Start |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Supplier Device Package | 6-TSSOP |
| ROHS |  |
NEX80801DAZ.pdf
